Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X125-40
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X125-40 Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X125-40
- Bore size: 20mm
- Stroke: 125mm
- Adjustment range: ±5° (end position angle adjustment)
- Operating pressure: 0.15–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning type: Adjustable air cushion
- Port size: M5x0.8 (standard) / Optional NPT1/8
- Mounting type: Foot-mounted (ISO 6432 compliant)
- Material: Aluminum alloy body, CR seals
- Weight: 0.48kg (bare cylinder)
- Dimensions: 200mm(L) × 40mm(W) × 40mm(H) (extended length)
- Rod thread: M6x1.0 external thread
- Max theoretical force: 50N @ 0.6MPa
- Lubrication: Pre-lubricated (DOP mist compatible)
- Protection rating: IP54 (standard wiper)
Ultra-compact cylinder with angular position adjustment capability, featuring a lightweight aluminum construction and integrated shock absorption. The unique rotary end lock mechanism enables precise stroke fine-tuning (±5°) without disassembly. Optimized for high-cycle applications requiring space efficiency and mid-stroke positioning flexibility.
- PCB handling robots in electronics assembly
- Precision valve actuation in medical devices
- Modular conveyor sorting systems
- Semiconductor wafer positioning stages
- Automated test equipment jig controls
Installation note:
For optimal angular adjustment performance, lubricate pivot points monthly with ISO VG32 turbine oil.
Maintain 0.3-0.5mm clearance between cushion screws and end caps during initial installation.
| Property | Property Value |
|---|---|
| sku | MBLJ20X125-40 |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
