Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X125-40S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X125-40S Adjustable Aluminum Miniature Cylinder Specifications
- Model: MBLJ20X125-40S
- Bore size: 20mm
- Stroke: 125mm (adjustable)
- Material: Anodized aluminum alloy body, CR seals
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion
- Port size: M5x0.8 dual ports
- Rod end: M6x1.0 external thread
- Mounting: Standard side boss (ISO 15552 compatible)
- Weight: 0.62kg
- Dimensions: 215mm(L) × 34mm(W) × 34mm(H)
- Stroke tolerance: ±1.5mm
- Max speed: 750mm/s
- Protection class: IP54 (standard)
Ultra-compact cylinder with patented position-lock mechanism for precise stroke adjustment (±3mm fine-tuning). Features wear-resistant rod bearing and double-sealed piston for maintenance-free operation. Includes built-in auto-lubrication design for dry air environments. Requires 5μm filtered air with ISO VG32 lubricant (optional).
- Precision clamping in CNC tool changers
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- High-cycle textile machinery actuators
- Laboratory automation positioning stages
Installation tip:
For vertical mounting, use anti-drop locknut (ASNU-6 accessory). Maintain 0.5-1mm
clearance between rod end and load during alignment. Pre-charge cushion chamber
with 0.05MPa air before first operation.
| Property | Property Value |
|---|---|
| sku | MBLJ20X125-40S |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
