Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X125-50
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X125-50 Adjustable Aluminum Miniature Cylinder Specifications
- Model: MBLJ20X125-50
- Type: Double-acting adjustable stroke cylinder
- Bore diameter: 20mm
- Stroke: 125mm (adjustable range: 50-125mm)
- Mounting style: Basic type with front thread (M10x1.25)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (standard) with optional NPT1/8 adapter
- Cushioning: Rubber buffer + adjustable stroke mechanism
- Body material: Anodized aluminum alloy (A6063)
- Piston rod material: Stainless steel (SUS304)
- Seal material: Polyurethane (PU) with wear-resistant ring
- Weight: 680g ±2% (including mounting accessories)
- Dimensions:
- Length (retracted): 195mm
- Length (extended): 320mm
- Body width: 34mm
- Height (with rod): 52mm
- Max speed: 500mm/s
- Protection rating: IP54 (standard wiper seal)
Ultra-compact profile cylinder with precision stroke adjustment capability, featuring a unique dual-locking mechanism for position retention. The 360° rotatable mounting threads enable flexible installation in confined spaces. Optimized air passage design reduces flow resistance by 30% compared to conventional mini cylinders.
- Precision positioning in semiconductor handling robots
- Clamping mechanisms for CNC tool changers
- Medical device actuation systems
- Packaging machine ejector mechanisms
- Automated test equipment positioners
Operation note:
Requires initial lubrication with ISO VG32 hydraulic oil.
For adjustable stroke function, always loosen the lock nut before rotating the stroke adjuster.
Avoid side load exceeding 15N during operation.
- Mounting brackets: MA-10 series
- Magnetic sensors: D-M9N/D-M9P
- Speed controllers: ASC-2000-02
| Property | Property Value |
|---|---|
| sku | MBLJ20X125-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
