Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X125-50S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X125-50S Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X125-50S
- Bore size: 20mm
- Stroke: 125mm (adjustable ±2mm)
- Operation: Double-acting
- Material: Anodized aluminum alloy body, CR12MoV piston rod
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Rubber buffer + adjustable screw
- Port size: M5x0.8 (G1/8 adapter available)
- Mounting type: Basic type (no foot)
- Weight: 550g ±5%
- Dimensions:
- Extended length: 234mm
- Retracted length: 109mm
- Body width: 38mm
- Height with rod: 57mm
- Rod thread: M6x1.0
- Lubrication: Pre-lubricated (DOP anti-wear oil)
- ISO standard: Compliant with ISO 6432
Ultra-compact cylinder with position-locking mechanism, featuring dual anti-rotation design for precise linear motion control. The hardened piston rod and triple sealing system (NBR + PU + dust scraper) ensure durability in high-cycle applications (up to 5 million cycles). Includes manual override adjustment screws for fine-tuning stroke endpoints.
- PCB handling robots in electronics manufacturing
- Precision valve actuation in analytical instruments
- Compact clamping fixtures for CNC tooling
- Pharmaceutical blister packaging machines
- Automated microscope stage positioning
Installation tip:
For vertical mounting, add 20% extra pressure margin to compensate for gravity load.
Use thread locker on adjustment screws after calibration. Lubricate every 500km of cumulative stroke
movement in dusty environments.
| Property | Property Value |
|---|---|
| sku | MBLJ20X125-50S |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
