Airtac MBLJ Adjustable Aluminum Alloy Mini Cylinder MBLJ20X125-75S
2. Riveted aluminum-clad structure integrates front/rear end caps with aluminum alloy cylinder for enhanced connection reliability;
3. Compact asymmetric bidirectional piston sealing design with integrated oil reservoir functionality;
4. Multiple rear end cap configurations facilitate flexible installation options;
5. Comprehensive selection of standard cylinder sizes and mounting accessories available.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MBLJ Adjustable Cylinder Series
AirTAC MBLJ20X125-75S Adjustable Aluminum Mini Cylinder Specifications
- Model: MBLJ20X125-75S
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 125mm (adjustable cushion)
- Adjustment range: ±3mm (total 6mm cushion stroke)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting style: Female thread (NF-M6×1.0)
- Port size: M5×0.8 (standard) / NPT1/8 optional
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Max speed: 500mm/s
- Weight: 0.62kg (excluding accessories)
- Dimensions:
- Extended length: 204mm
- Retracted length: 79mm
- Body diameter: 32mm
- Rod end thread: M6×1.0
Compact linear actuator with precision cushion adjustment, featuring a double-acting design and corrosion-resistant construction. The dual adjustable buffers enable smooth end-of-stroke deceleration, reducing impact noise below 75dB. Integrated mounting threads allow direct installation in confined spaces.
- PCB handling robots in electronics assembly
- Precision clamping mechanisms for CNC tooling
- Pharmaceutical blister packaging machines
- Automated test equipment positioners
- Cleanroom material handling systems
Installation note:
For optimal performance, maintain 0.5-1mm clearance between cushion screw and piston during adjustment. Lubricate with ISO VG32 hydraulic oil before initial use. Avoid side load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | MBLJ20X125-75S |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
