Airtac MCK Welding Clamping Cylinder MCK80X100-S-Y
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X100-S-Y Welding Clamping Cylinder Technical Details
- Model Code: MCK80X100-S-Y
- Type: Double-acting welded clamping cylinder
- Bore size: Ø80 mm
- Stroke: 100 mm
- Operating pressure: 0.1–1.0 MPa
- Temperature range: -10℃ to 150℃ (peak resistance)
- Port size: Rc1/4 (standard) / NPT1/4 (optional)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Front/rear flange (ISO 15552 compatible)
- Rod thread: M20×1.5 (external)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal type: High-temp NBR seals with wear ring
- Weight: 3.8 kg ±2% (without accessories)
- Dimensions: 212mm(L) × 95mm(W) × 95mm(H) (at retracted position)
- Protection class: IP54 (standard wiper design)
- Lubrication: Pre-lubricated (Grease-free operation possible)
Heavy-duty clamping cylinder specifically engineered for welding fixture applications. Features enhanced heat-resistant seals (withstands welding spatter up to 150℃ intermittently) and anti-vibration design. The reinforced flange structure provides 15% higher rigidity than standard cylinders, making it ideal for high-shock environments.
- Robotic welding positioners in automotive assembly
- Pipe flange clamping during TIG/MIG welding
- Jig fixtures for battery pack spot welding
- Forging press mold holding systems
- High-frequency induction heating workholding
Installation protocol:
Use heat-resistant mounting brackets (not included). Maintain 0.5-1mm clearance between cylinder body and welding area. Apply anti-spatter spray on exposed surfaces. Perform weekly air filter drainage when used in continuous operation.
| Property | Property Value |
|---|---|
| sku | MCK80X100-S-Y |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
