Airtac MCK Welding Clamping Cylinder MCK80X100S
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X100S Welding Clamping Cylinder Specifications
- Model: MCK80X100S
- Type: Double-acting welded clamping cylinder
- Bore size: Ø80mm
- Stroke: 100mm
- Operating pressure: 0.2–1.0 MPa
- Temperature range: -10℃ to 150℃ (peak resistance)
- Mounting style: Fixed flange with reinforced base
- Port size: G1/2 (ISO228 standard)
- Cushioning: Adjustable hydraulic buffer + rubber pad
- Rod material: Hard chrome-plated steel (5μm coating)
- Cylinder tube: Anodized aluminum alloy (25μm surface treatment)
- Seal type: High-temp NBR seals with wear ring
- Weight: 3.5kg (excluding mounting accessories)
- Dimensions: 280mm(L) × 125mm(W) × 125mm(H)
- Rod thread: M20×1.5 external thread
- Protection class: IP54 (standard dust/moisture resistance)
Heavy-duty clamping cylinder specifically engineered for welding fixture applications. Features heat-resistant seals and anti-spatter coating (3μm PTFE layer) for arc welding environments. The reinforced base plate withstands 15kN lateral forces, with 0.05mm repeat positioning accuracy. Requires 5-40μm filtered air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Robotic welding positioners in automotive assembly
- Pipe flange alignment in heavy machinery
- Jig clamping for CNC plasma cutting tables
- High-temperature furnace door locking systems
- Press brake tooling fixation
Installation protocol:
Apply anti-seize compound (MoS2-based) on rod threads before operation.
Maintain 0.5-0.8 MPa pressure during initial 50 cycles for seal conditioning.
Use 2-point symmetrical clamping force ≤800N·m.
| Property | Property Value |
|---|---|
| sku | MCK80X100S |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
