Airtac MCK Welding Clamping Cylinder MCK80X100SEYW
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X100SEYW Welding Clamping Cylinder Specifications
- Model: MCK80X100SEYW
- Type: Welding-specific clamping cylinder (double-acting)
- Bore size: 80mm
- Stroke: 100mm
- Operating pressure: 0.1–0.8 MPa
- Operating medium: Clean air (40μm filtered)
- Mounting style: Side flange mounting (ISO 15552 standard)
- Port thread: M14x1.5 (dual ports)
- Cushioning: Adjustable pneumatic cushion
- Seal material: Heat-resistant NBR (+5℃ to +100℃)
- Ambient temperature: -10℃ to +70℃
- Piston rod material: Hard chrome-plated steel
- Weight: 5.8kg (including mounting accessories)
- Dimensions: 280mm(L) × 125mm(W) × 100mm(H)
- Protection rating: IP54 (standard wiper seal)
- Max thrust: 4020N @0.6MPa
Heavy-duty welding cylinder with reinforced structure and heat-resistant seals, featuring anti-spatter coating on exposed surfaces. The asymmetric flange design allows direct fixture mounting in high-temperature environments. Integrated magnetic slots enable position sensing compatibility.
- Robotic welding fixture systems
- Automotive chassis component clamping
- High-temperature metal stamping presses
- Pipe welding positioners
- Forging machine tooling
Installation note:
Apply high-temperature grease (≥200℃ rating) to rod surface before initial use.
Maintain 0.3mm minimum clearance between clamp arm and cylinder body during thermal expansion.
| Property | Property Value |
|---|---|
| sku | MCK80X100SEYW |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
