Airtac MCK Welding Clamping Cylinder MCK80X100SYW
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK Welding Clamping Cylinder MCK80X100SYW Specifications
- Model: MCK80X100SYW
- Type: Double-acting welded clamping cylinder
- Bore size: Ø80 mm
- Stroke: 100 mm
- Mounting style: SYW series square flange mounting
- Operating pressure: 0.1-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable buffer at both ends
- Port size: G1/2 (ISO228 standard)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy with hard anodized surface
- Seal material: High-temperature resistant NBR
- Weight: 5.8 kg (excluding mounting accessories)
- Dimensions: 312mm(L) × 125mm(W) × 125mm(H) (full extension)
- Protection rating: IP54 (standard), IP67 optional
- Max lateral load capacity: 850N at full extension
Heavy-duty welding clamp cylinder designed for high-precision fixturing in automated welding systems. Features reinforced rod bearings and anti-spatter coating (0.2mm thickness) on exposed surfaces. The SYW flange allows 360° mounting position adjustment with 4×M10 mounting holes (12mm depth). Requires 5μm filtered air with ISO VG32 lubricator oil.
- Robotic welding stations in automotive manufacturing
- Pipe flange alignment in structural welding
- Jig clamping for sheet metal spot welding
- High-temperature resistance welding environments
- Position locking in CNC welding turntables
Operation note:
Maintain 0.3-0.6 MPa working pressure for optimal clamp force (12.5kN at 0.5MPa).
Lubricate guide shafts every 500,000 cycles using ISO VG32 oil. Avoid angular
loads exceeding ±2° deviation.
| Property | Property Value |
|---|---|
| sku | MCK80X100SYW |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
