Airtac MCK Welding Clamping Cylinder MCK80X100YW
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X100YW Welding Clamping Cylinder Specifications
- Model: MCK80X100YW
- Type: Compact welded clamping cylinder (double-acting)
- Bore size: 80 mm
- Stroke: 100 mm
- Operating pressure: 0.1–1.0 MPa
- Operating temperature: -10℃ to 150℃ (high-temp seals)
- Port size: G1/8 (NPT1/8 optional)
- Mounting style: Y-type flange with 4xM8 threaded holes
- Material: Aluminum alloy body, hardened stainless steel piston rod
- Cushioning: Adjustable rubber buffers at both ends
- Repeat position accuracy: ±0.2 mm
- Weight: 3.8 kg (excluding accessories)
- Dimensions: 282mm(L) × 108mm(W) × 108mm(H)
- Rod end thread: M20×1.5
- Seal material: High-temperature resistant fluororubber (FKM)
- Protection rating: IP67 (wipers included)
Heavy-duty welding clamp cylinder specifically engineered for robotic welding stations and fixture applications. Features enhanced heat resistance with FKM seals and anti-spatter coating on exposed surfaces. The reinforced piston rod (HRC45-50 hardness) withstands lateral forces during clamping operations. Includes magnetic switch grooves for position feedback integration.
- Robotic welding jigs in automotive assembly lines
- High-temperature metal stamping positioning
- Foundry mold clamping during casting processes
- Battery pack welding fixtures for EV manufacturing
- Heavy plate alignment in structural steel fabrication
Installation note:
Apply high-temperature grease (≥200℃ rating) to rod surface before initial use.
Maintain 0.5-1mm clearance between clamp arm and cylinder body for thermal expansion.
Use copper-based anti-seize compound on mounting threads in high-heat environments.
| Property | Property Value |
|---|---|
| sku | MCK80X100YW |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
