Airtac MCK Welding Clamping Cylinder MCK80X120Y
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK Welding Clamping Cylinder MCK80X120Y Technical Details
- Model: MCK80X120Y
- Type: Double-acting welded clamping cylinder
- Bore size: 80mm (ISO 6432 standard)
- Stroke: 120mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 150℃ (peak resistance)
- Mounting style: Fixed flange (ISO 15552-MF1 pattern)
- Port size: G1/4 (BSPP thread)
- Cushioning: Adjustable pneumatic buffer
- Piston rod material: Hard chrome-plated steel (Cr-Mo alloy)
- Tube material: Anodized aluminum alloy (AL6063-T5)
- Seal type: High-temp NBR with wear-resistant guide rings
- Weight: 12.8kg (excluding mounting accessories)
- Dimensions: 298mm(L) × 92mm(W) × 92mm(H) (stroke extended)
- Rod end thread: M20×1.5 (ISO 12240-2)
- Protection class: IP54 (standard wiper seal)
Heavy-duty welding clamp cylinder with reinforced structure, featuring a non-rotating piston rod and precision ground inner tube for stable clamping force. The Y-suffix design incorporates heat-resistant seals and flame-retardant wipers, specifically engineered for robotic welding stations. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Robotic welding fixture positioning in automotive assembly
- High-temperature metal stamping die clamping
- Foundry mold locking during casting processes
- Heavy plate jig systems for shipbuilding
- Forging press tool retention mechanisms
Installation protocol:
Maintain 0.02mm/m alignment tolerance during mounting. Apply anti-spatter spray
(PFOA-free) to cylinder body in welding environments. Perform lubrication every
50,000 cycles using ISO VG32 hydraulic oil mist.
| Property | Property Value |
|---|---|
| sku | MCK80X120Y |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 120mm |
