Airtac MCK Welding Clamping Cylinder MCK80X125-Y
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X125-Y Welded Clamping Cylinder Specifications
- Model: MCK80X125-Y
- Type: Double-acting welded clamping cylinder
- Bore size: Ø80 mm
- Stroke: 125 mm
- Operating pressure: 0.1–0.8 MPa
- Port size: G1/2 (ISO228/1 standard)
- Cushioning: Adjustable pneumatic cushion
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 5.8 kg (excluding accessories)
- Dimensions: 300mm(L) × 96mm(W) × 96mm(H) (at fully retracted position)
- Mounting style: Front flange mounting (ISO15552 standard)
- Protection rating: IP54 (standard), IP67 optional
Heavy-duty welded cylinder with integrated clamping mechanism, featuring a reinforced structure for high rigidity and precise positioning. The Y-suffix model includes enhanced sealing for particulate environments and anti-vibration lock nuts. Requires 5μm filtered air with ISO VG32 lubricator for optimal performance.
- Robotic welding fixture systems
- Automotive chassis assembly jigs
- CNC machine tool clamping units
- Forging press positioning locks
- Heavy material handling automation
Installation note:
Maximum lateral load capacity 350N. Use M12x1.25 mounting bolts (grade 8.8 or higher).
Maintain 0.5-1mm clearance between clamp arm and workpiece surface during initial setup.
| Property | Property Value |
|---|---|
| sku | MCK80X125-Y |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 125mm |
