Airtac MCK Welding Clamping Cylinder MCK80X125SYW
$146.52
Regular price
$154.02
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MCK80X125SYW
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
**Product Description:**
1. Engineered for automotive welding workshop environments, offering superior resistance to high temperatures and contamination;
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
Installation note:
Ensure proper alignment of clamping surfaces using alignment pins (not included).
Recommended 0.5-0.7 MPa operating pressure for optimal grip force.
Apply thread locker on mounting bolts (M10×1.25, grade 8.8 or higher).
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X125SYW Welded Clamping Cylinder Specifications
- Model: MCK80X125SYW
- Type: Compact welded body clamping cylinder (double-acting)
- Bore size: 80mm
- Stroke: 125mm
- Mounting style: SYW series flange mounting (front/rear dual flange)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable rubber buffer + shock absorber pad
- Port size: G3/8 (standard) with NPT1/2 optional
- Rod end thread: M20×1.5 (external thread)
- Seal material: High-temp NBR + polyurethane hybrid seals
- Protection rating: IP54 (standard), IP67 optional
- Weight: 3.8kg (bare cylinder), 4.2kg (with accessories)
- Dimensions: 298mm(L) × 80mm(Bore diameter) × 115mm(Flange width)
- Rod diameter: 25mm chrome-plated steel
- Max thrust: 5020N @ 0.63MPa
- Lubrication: Pre-lubricated (Grease-free operation compatible)
Heavy-duty welded cylinder with integrated clamping mechanism, featuring reinforced end caps and anti-vibration flanges. The square body design prevents rotation during operation. Optimized for high side load applications with tungsten-treated piston rod surface (3-5μm hardness layer). Includes magnetic piston for position sensing compatibility.
Typical Applications:
- Robotic welding fixture positioning in automotive assembly
- Press brake tooling clamping systems
- CNC machining center workpiece locking
- Forging die retention in metal stamping
- High-temperature mold fixing in die casting
Installation note:
Ensure proper alignment of clamping surfaces using alignment pins (not included).
Recommended 0.5-0.7 MPa operating pressure for optimal grip force.
Apply thread locker on mounting bolts (M10×1.25, grade 8.8 or higher).
Maintenance:
Relubricate every 500km of cumulative stroke movement using ISO VG32 hydraulic oil.
Inspect rod seals every 6 months in continuous operation environments.
| Property | Property Value |
|---|---|
| sku | MCK80X125SYW |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 125mm |
