Airtac MCK Welding Clamping Cylinder MCK80X150-S-Y
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X150-S-Y Welded Clamping Cylinder Specifications
- Model: MCK80X150-S-Y
- Type: Compact welded clamping cylinder (double-acting)
- Bore size: 80mm (ISO 6432 standard)
- Stroke: 150mm (±0.5mm tolerance)
- Mounting: Side welded base with reinforced gussets
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Temperature range: -20℃ to 80℃ (non-lubricated)
- Port size: 1/4" NPT (M5×0.8 optional)
- Cushioning: Adjustable rubber buffers at both ends
- Seal material: Heat-resistant NBR (Nitrile)
- Protection rating: IP40 (dust protected)
- Weight: 5.8kg (12.8 lbs) ±3%
- Dimensions: 80mm (Dia) × 235mm (L) × 95mm (H)
- Rod thread: M20×1.5 external thread (ISO 12240-2)
- Max thrust: 402N @ 0.6MPa (90.4 lbf)
Heavy-duty welded cylinder with integrated mounting base, designed for permanent installation in high-vibration environments. Features anti-rotation keyway (3mm × 3mm) and hardened piston rod (HRC 45-50) with chrome plating (15-20μm). Requires 5μm filtered air with ISO 8573-1:2010 Class 3.2.4 purity.
- Robotic welding fixture clamping systems
- Automotive chassis component positioning
- Foundry mold locking mechanisms
- Heavy part jigging in CNC machining centers
- High-temperature press tool retention
Installation note:
Weld using 490-590MPa yield strength electrodes at 0.8-1.2mm leg length.
Allow 48-hour cooling period before pressurization. Maintain 0.3mm minimum
clearance between rod end and workpiece during alignment.
| Property | Property Value |
|---|---|
| sku | MCK80X150-S-Y |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 150mm |
