Airtac MCK Welding Clamping Cylinder MCK80X50-Y
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X50-Y Welding Clamping Cylinder Specifications
- Model: MCK80X50-Y
- Type: Double-acting welded clamping cylinder
- Bore size: Ø80 mm
- Stroke: 50 mm (±0.5 mm tolerance)
- Operating pressure: 0.1–1.0 MPa
- Max thrust: 3,140 N @ 0.5 MPa
- Piston speed: 50–700 mm/s
- Temperature range: -20℃ to 80℃
- Mounting type: Front flange with 4×M10 threaded holes
- Rod end: M30×1.5 external thread
- Port size: G1/4 (NPT1/4 optional)
- Cushioning: Adjustable rubber buffer
- Material: Aluminum alloy body (A6063-T5), CR12MoV piston rod
- Seal type: HNBR seals with wear-resistant ring
- Weight: 4.8 kg (without accessories)
- Dimensions: 300mm(L) × 112mm(W) × 112mm(H)
- Protection rating: IP54 (standard), IP67 (optional)
Heavy-duty welding clamp cylinder with precision ground rod and anti-rotation mechanism. Features integrated mounting flanges for direct welding to jigs/fixtures. The chrome-plated piston rod incorporates a dust wiper to prevent spatter contamination. Requires 5-40μm filtered air with ISO VG32 lubricant.
- Robotic welding positioners in automotive assembly
- Pipe flange alignment systems
- CNC machining fixture clamping
- Heat exchanger plate pressing
- Forging die holding mechanisms
Installation note:
Weld mounting surface must be machined flat (Ra≤6.3μm).
Maintain 0.5mm gap between cylinder base and welding fixture
to prevent thermal deformation. Apply high-temperature
grease (≥200℃ rating) for foundry applications.
| Property | Property Value |
|---|---|
| sku | MCK80X50-Y |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <50mm> |
