Airtac MCK Welding Clamping Cylinder MCK80X75-S-Y
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X75-S-Y Welded Clamping Cylinder Specifications
- Model: MCK80X75-S-Y
- Type: Welded compact clamping cylinder
- Bore size: 80mm
- Stroke: 75mm
- Mounting type: Square flange (ISO 15552 compatible)
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Piston rod material: Chrome-plated carbon steel
- Tube material: Precision-welded steel construction
- Seal type: Heat-resistant NBR seals
- Cushioning: Adjustable pneumatic cushioning
- Port size: PT1/4 (G1/4 optional)
- Weight: 3.8kg ±2%
- Dimensions: 225mm(L) × 105mm(W) × 105mm(H)
- Protection class: IP54 (standard), IP67 (optional)
- Lubrication: Pre-lubricated (Grease-free operation)
Heavy-duty welded cylinder designed for high rigidity clamping applications. Features a reinforced square flange structure that withstands 300% higher lateral forces compared to standard cylinders. The plasma-welded body eliminates leakage risks and maintains stability under continuous vibration. Includes wear-resistant guide bushings and anti-rotation mechanism for precision positioning.
- Robotic welding fixture systems
- Automotive chassis assembly jigs
- CNC machining center workpiece clamping
- Forging press die positioning
- High-temperature foundry equipment
Installation note:
Ensure mounting surface flatness ≤0.1mm/m². Use M10 grade 12.9 mounting bolts
with 45-50Nm torque. Maintain 0.3-0.5mm clearance between clamp arm and cylinder
body during alignment. Lubricate guide rods every 500,000 cycles using ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | MCK80X75-S-Y |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 75mm |
