Airtac MCK Welding Clamping Cylinder MCK80X75-Y
2. Front cover equipped with stainless steel wipers for enhanced durability, effectively shielding the cylinder from dust and welding spatter—more reliable than traditional dust boots;
3. Anti-interference sensors recommended for applications in strong magnetic fields;
4. Triple-sided port configuration with optional inlet positions, integrated cushioning adjustment, and speed control via built-in flow regulators;
5. Multiple sensor types available for flexible signal feedback.
**Category:** Clamping Cylinders | **Brand:** AIRTAC | **Series:** MCK
AirTAC MCK80X75-Y Welding Clamp Cylinder Specifications
- Model: MCK80X75-Y
- Type: Double-acting welded clamp cylinder (ISO 6432 compliant)
- Bore size: 80 mm
- Stroke: 75 mm (±0.5 mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Mounting style: Fixed rectangular base with 4x M8 threaded holes
- Cushioning: Adjustable pneumatic cushion at both ends
- Temperature range: -20℃ to 150℃ (continuous use)
- Seal material: Heat-resistant NBR with PTFE coating
- Port size: G1/4 (BSPP thread)
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy (AL6063-T5)
- Weight: 4.8 kg (without accessories)
- Dimensions: 200mm(L) × 105mm(W) × 105mm(H)
- Max thrust: 502 N @ 0.6 MPa
- Repeat positioning accuracy: ±0.2 mm
- IP rating: IP54 (standard), IP67 optional
Heavy-duty welding clamp cylinder engineered for high-temperature industrial environments. Features reinforced heat shielding on the front end (up to 150℃ continuous exposure) and anti-spatter coating. The Y-suffix denotes enhanced weld spatter resistance and copper-free construction for automotive production lines. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Robotic welding fixture systems in automotive assembly
- High-frequency resistance welding machines
- Forging press part positioning
- Laser cutting workpiece clamping
- Foundry mold locking mechanisms
Installation note:
Mount using M8 grade 8.8 bolts with spring washers. Apply high-temperature
molybdenum grease to rod weekly in continuous operation. Maintain 50mm
minimum clearance from welding arc zone. Use with heat-resistant tubing
(not included).
| Property | Property Value |
|---|---|
| sku | MCK80X75-Y |
| Mounting Fixation Type | Double Hinged Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°C Speed Range: 50-500 mm/s |
| Port Size | PT3/8 |
| Lubrication | Please provide the specific AirTAC product attribute values that need translation, and I will return the accurate English terminology. |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 75mm |
