Airtac MD Multi-Position Clamping Cylinder MD20X25
2. Features multiple mounting configurations on the main body for simplified installation and operation;
3. Supports parallel consolidation of multiple cylinders to optimize space efficiency in compact layouts;
4. Integrated high-precision piston rod guidance system eliminates the need for external lubrication;
5. Comprehensive model range available to meet customized application requirements;
6. Optional high-temperature resistant sealing materials ensure stable operation at 150°C environments. (Optional feature)
Category: Multi-position Locking Cylinders | Brand: AIRTAC | Series: MD
AirTAC MD20X25 Multi-Position Locking Cylinder Specifications
- Model: MD20X25
- Type: Double-acting multi-position locking cylinder
- Bore size: 20mm
- Stroke: 25mm
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 80℃
- Port size: Rc1/8 (G1/8 optional)
- Locking positions: 3 (extended/retracted/mid-stroke)
- Cushioning: Adjustable pneumatic cushion
- Mounting style: Basic type (MF1)
- Rod material: Chrome-plated steel
- Tube material: Aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 0.82kg ±5%
- Dimensions:
- Total length (retracted): 125mm
- Body diameter: 32mm
- Rod diameter: 8mm
- Mounting hole spacing: 25mm (front) / 40mm (rear)
Precision locking cylinder with triple-position memory function, featuring mechanical locking pins activated by air pressure. The anodized aluminum body provides corrosion resistance, while the chrome-plated piston rod ensures smooth operation. Includes magnetic sensor slots (M9x1 thread) for position feedback. Requires 5μm filtered air with ISO VG32 lubricant.
- Position-stable tool changers in CNC machines
- Multi-stage clamping fixtures for welding robots
- Conveyor gate positioning systems
- Printing press paper feed mechanisms
- Automated assembly line stoppers
Installation note:
Maintain 0.5-1mm clearance between locking pin holes and positioning blocks.
Perform position calibration after installation using manual override button.
Lubricate every 50km of cumulative stroke.
| Property | Property Value |
|---|---|
| sku | MD20X25 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | <25 mm> |
