Airtac MD Multi-Position Clamping Cylinder MD20X30
2. Features multiple mounting configurations on the main body for simplified installation and operation;
3. Supports parallel consolidation of multiple cylinders to optimize space efficiency in compact layouts;
4. Integrated high-precision piston rod guidance system eliminates the need for external lubrication;
5. Comprehensive model range available to meet customized application requirements;
6. Optional high-temperature resistant sealing materials ensure stable operation at 150°C environments. (Optional feature)
Category: Multi-position Locking Cylinders | Brand: AIRTAC | Series: MD
AirTAC MD20X30 Multi-Position Locking Cylinder Specifications
- Model: MD20X30
- Type: Double-acting multi-position locking cylinder
- Bore size: 20mm
- Stroke: 30mm
- Operating pressure: 0.15–0.8 MPa
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Locking mechanism: Mechanical wedge system with 3-5 preset positions
- Cushioning: Adjustable air cushion at both ends
- Temperature range: -20℃ to 80℃
- Cylinder tube material: Hard anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Piston rod material: Chrome-plated steel
- Weight: 0.45kg ±5%
- Dimensions: 160mm(L) × 70mm(W) × 70mm(H) (fully retracted)
- Mounting type: ISO 15552 standard mounts (accessory dependent)
- Position accuracy: ±0.2mm (with proper air filtration)
- Max lateral load: 15N at full extension
Precision locking cylinder with mechanical position memory function, featuring a unique multi-stage wedge locking system for intermediate stroke fixation. The hardened piston rod and double lip seals ensure durability in high-cycle applications. Requires 5μm filtered air and regular lubrication (ISO VG32 hydraulic oil recommended).
- Rotary indexing table positioning
- Modular fixture systems in CNC machining
- Multi-stage press tool height adjustment
- Automated assembly line workpiece staging
- Packaging machine gate positioning
- Robotic arm tool changer mechanisms
Installation note:
Mounting surface flatness must be within 0.05mm. Locking positions should be set with cylinder unpressurized.
Allow 1-2mm free play in mounting brackets to prevent side load binding. Perform initial lubrication cycle (10 full strokes) before operation.
| Property | Property Value |
|---|---|
| sku | MD20X30 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | 30mm |
