Airtac MD Multi-Position Clamping Cylinder MD20X40
2. Features multiple mounting configurations on the main body for simplified installation and operation;
3. Supports parallel consolidation of multiple cylinders to optimize space efficiency in compact layouts;
4. Integrated high-precision piston rod guidance system eliminates the need for external lubrication;
5. Comprehensive model range available to meet customized application requirements;
6. Optional high-temperature resistant sealing materials ensure stable operation at 150°C environments. (Optional feature)
Category: Multi-position Locking Cylinders | Brand: AIRTAC | Series: MD
AirTAC MD Series Multi-Position Locking Cylinder MD20X40 Technical Details
- Model Code: MD20X40
- Bore Size: 20mm (ISO 6432 standard)
- Stroke: 40mm ±1mm
- Operating Pressure: 0.1–0.9 MPa
- Port Thread: G1/8 (BSPP) dual ports
- Locking Positions: 3 fixed positions (customizable up to 5)
- Piston Speed: 50–700 mm/s (lubricated condition)
- Buffer Type: Adjustable rubber cushion (both ends)
- Ambient Temp Range: -10℃ to 80℃
- Seal Material: NBR + Polyurethane hybrid
- Rod Material: Hard chrome-plated steel (3μm coating)
- Tube Finish: Anodized aluminum alloy
- Weight: 0.82kg ±3%
- Dimensions (L×W×H): 160mm × 42mm × 42mm (extended length: 200mm)
- Mounting: ISO 15552 foot mounting (accessory kit optional)
- Position Accuracy: ±0.3mm (with air cushion engaged)
- Protection Class: IP54 (standard wiper seal)
Precision multi-station pneumatic actuator with mechanical locking mechanism, featuring position memory function through integrated ratchet system. The dual-chamber design maintains holding force even during air supply interruptions. Optimized for repetitive positioning tasks requiring intermediate stops.
- Rotary indexing table positioning in assembly machines
- Modular fixture height adjustment systems
- PCB handling equipment with multiple pick-up levels
- Glass cutting machinery with progressive depth control
- Automated warehouse vertical lift positioning
Installation Protocol:
Requires 0.5Nm torque for mounting bolts with thread locker.
Perform 10-15 dry cycles before load operation. Maintain 0.3MPa minimum
pressure for position locking engagement. Lubricate every 50km of cumulative stroke.
| Property | Property Value |
|---|---|
| sku | MD20X40 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | <40mm> |
