Airtac MD Multi-Position Clamping Cylinder MD20X5
2. Features multiple mounting configurations on the main body for simplified installation and operation;
3. Supports parallel consolidation of multiple cylinders to optimize space efficiency in compact layouts;
4. Integrated high-precision piston rod guidance system eliminates the need for external lubrication;
5. Comprehensive model range available to meet customized application requirements;
6. Optional high-temperature resistant sealing materials ensure stable operation at 150°C environments. (Optional feature)
Category: Multi-position Locking Cylinders | Brand: AIRTAC | Series: MD
AirTAC MD Series Multi-Position Locking Cylinder MD20X5 Technical Details
- Model: MD20X5
- Type: Multi-position mechanically locked pneumatic cylinder
- Bore size: Ø20 mm
- Stroke: 5 mm (standard locking intervals)
- Working pressure: 0.1–0.9 MPa
- Operating temperature: -10℃ to 70℃
- Buffer type: Fixed cushioning (both ends)
- Mounting style: ISO 15552 standard flange mounts
- Port size: M5x0.8 (dual ports at both ends)
- Rod material: Stainless steel SUS304
- Cylinder tube: Anodized aluminum alloy
- Seal material: High-wear NBR rubber
- Weight: 0.45 kg (excluding accessories)
- Dimensions: 150mm(L) × 40mm(W) × 40mm(H) (retracted position)
- Position accuracy: ±0.2 mm (repeat positioning)
- Locking force: 120 N (at 0.5 MPa)
- Protection class: IP54 (standard sealing)
Precision multi-station cylinder featuring mechanical position locking via spring-loaded ball detents. The MD20X5 delivers 5 discrete locking positions with positive engagement, ideal for tooling applications requiring repeatable intermediate stops. Enhanced wear resistance through chrome-plated piston rod and dual wiper seals. Includes magnetic piston for position sensing compatibility.
- Fixture positioning in CNC machining centers
- Modular assembly station indexing
- Precision clamping mechanisms
- Semiconductor wafer handling systems
- Automated inspection equipment stops
Installation note:
Requires clean, lubricated air (ISO 8573-1:2010 Class 3-4-3).
Position locks engage only when cylinder is depressurized -
always verify mechanical engagement before system restart.
Minimum 1.5x bore size clearance required for lateral maintenance access.
| Property | Property Value |
|---|---|
| sku | MD20X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <20mm> |
| Stroke | <5mm> |
