Airtac MD Multi-Position Clamping Cylinder MD25X5
2. Features multiple mounting configurations on the main body for simplified installation and operation;
3. Supports parallel consolidation of multiple cylinders to optimize space efficiency in compact layouts;
4. Integrated high-precision piston rod guidance system eliminates the need for external lubrication;
5. Comprehensive model range available to meet customized application requirements;
6. Optional high-temperature resistant sealing materials ensure stable operation at 150°C environments. (Optional feature)
Category: Multi-position Locking Cylinders | Brand: AIRTAC | Series: MD
AirTAC MD Series Multi-position Locking Cylinder MD25X5 Technical Details
- Bore size: Ø25mm
- Stroke: 5mm (fixed position)
- Operating pressure: 0.05–0.9 MPa
- Locking positions: 3-5 programmable stops
- Piston speed: 50-700 mm/s
- Ambient temperature: -10℃ to 80℃
- Buffer type: Adjustable rubber cushion
- Mounting style: ISO 15552 standard flange (MF1/MF2 options)
- Rod end thread: M10×1.25
- Port size: G1/8 (NPT1/8 optional)
- Seal material: HNBR with wear-resistant guide rings
- Repeat positioning accuracy: ±0.2mm
- Weight: 1.8kg (with mounting bracket)
- Dimensions: 200mm(L) × 62mm(W) × 62mm(H) (extended length)
- Protection rating: IP54 (standard), IP67 with optional kit
- Certifications: RoHS compliant, ISO 6432 compatible
Precision multi-station pneumatic actuator featuring electromagnetic position locking mechanism. The MD25X5 combines servo-like positioning capability with pneumatic power, using internal magnetic sensors and mechanical locks for stable intermediate stops. Special chrome-plated rod treatment prevents particulate generation in clean environments.
- Semiconductor wafer handling robots
- Automated inspection station indexing
- Pharmaceutical blister packaging position control
- Glass panel polishing pressure adjustment
- EV battery module assembly fixtures
Installation protocol:
Requires filtered air (5μm) with lubricator (ISO VG32). Position sensor cables must be routed separately from power lines.
Allow 0.5mm lateral clearance during alignment. Cycle rate limited to 80% duty cycle above 5Hz operation.
| Property | Property Value |
|---|---|
| sku | MD25X5 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <25 mm> |
| Stroke | <5mm> |
