Airtac MD Multi-Position Clamping Cylinder MD25X70
2. Features multiple mounting configurations on the main body for simplified installation and operation;
3. Supports parallel consolidation of multiple cylinders to optimize space efficiency in compact layouts;
4. Integrated high-precision piston rod guidance system eliminates the need for external lubrication;
5. Comprehensive model range available to meet customized application requirements;
6. Optional high-temperature resistant sealing materials ensure stable operation at 150°C environments. (Optional feature)
Category: Multi-position Locking Cylinders | Brand: AIRTAC | Series: MD
AirTAC MD Series Multi-Position Locking Cylinder MD25X70 Specifications
- Model: MD25X70
- Bore size: 25mm
- Stroke: 70mm
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Locking positions: 3-5 programmable stops
- Buffer type: Adjustable pneumatic cushioning
- Mounting style: Side/Flange (ISO 15552 compatible)
- Port size: PT1/8 (M5x0.8 optional)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 0.62kg ±2%
- Dimensions: 150mm(L) × 34mm(W) × 34mm(H)
- Repeat positioning accuracy: ±0.2mm
- Max lateral load capacity: 15N
- Protection rating: IP54
The MD25X70 features a unique mechanical locking mechanism with position memory function, enabling precise intermediate stops without external sensors. Its dual piston design ensures stable holding force up to 35N·m. The cylinder incorporates wear-resistant guide bushings and a magnetic piston for position feedback compatibility. Requires filtered air (5-40μm) with ISO 8573-1:2010 Class 4.3.4 standards.
- Multi-stage press tool positioning
- Automated welding fixture height adjustment
- Packaging machine product height compensation
- Semiconductor handling equipment Z-axis control
- Automotive assembly line clamping sequences
Installation note:
Maintain 0.5mm alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
during initial setup. Avoid lateral loads exceeding 10% of maximum thrust capacity.
Position sensor cables must be routed separately from power lines.
| Property | Property Value |
|---|---|
| sku | MD25X70 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <25 mm> |
| Stroke | 70mm |
