Airtac MD Multi-Position Clamping Cylinder MD32X15
2. Features multiple mounting configurations on the main body for simplified installation and operation;
3. Supports parallel consolidation of multiple cylinders to optimize space efficiency in compact layouts;
4. Integrated high-precision piston rod guidance system eliminates the need for external lubrication;
5. Comprehensive model range available to meet customized application requirements;
6. Optional high-temperature resistant sealing materials ensure stable operation at 150°C environments. (Optional feature)
Category: Multi-position Locking Cylinders | Brand: AIRTAC | Series: MD
AirTAC MD32X15 Multi-Position Locking Cylinder Technical Details
- Model: MD32X15
- Bore size: 32mm
- Stroke: 15mm
- Operation: Double-acting with mechanical locking
- Locking positions: 3 fixed positions (extend/retract/mid-stroke)
- Working pressure: 0.1–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber buffer
- Port size: G1/8 (M5 optional)
- Mounting type: Foot/base mount (AF series accessories compatible)
- Rod material: Chrome-plated steel
- Tube material: Aluminum alloy oxidation
- Seal type: NBR + PU hybrid seals
- Weight: 1.2kg (without accessories)
- Dimensions: 150mm(L) × 32mm(W) × 32mm(H) (retracted state)
- ISO standard: 15552 compliant
- Repeat positioning accuracy: ±0.2mm
High-precision locking cylinder with triple-position control capability, featuring wear-resistant chromium plating and dual-stage sealing system. The integrated mechanical locking mechanism maintains position without continuous air supply, with 360° adjustable magnetic sensor slots for position feedback. Requires ISO 8573-1:2010 Class 3 compressed air.
- PCB board clamping in SMT assembly lines
- Tooling plate positioning in CNC fixtures
- Pallet height adjustment in automated warehouses
- Glass panel flipping mechanisms
- Robotic welding position locking
Installation guidelines:
Apply M3x0.5 mounting screws with 2.5Nm torque. Lubricate through Z6 port using ISO VG32 hydraulic oil.
Maintain 0.3mm minimum clearance between rod end and load during alignment.
| Property | Property Value |
|---|---|
| sku | MD32X15 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <32 mm> |
| Stroke | <15mm> |
