Airtac MD Multi-Position Clamping Cylinder MD32X60
2. Features multiple mounting configurations on the main body for simplified installation and operation;
3. Supports parallel consolidation of multiple cylinders to optimize space efficiency in compact layouts;
4. Integrated high-precision piston rod guidance system eliminates the need for external lubrication;
5. Comprehensive model range available to meet customized application requirements;
6. Optional high-temperature resistant sealing materials ensure stable operation at 150°C environments. (Optional feature)
Category: Multi-position Locking Cylinders | Brand: AIRTAC | Series: MD
AirTAC MD32X60 Multi-Position Locking Cylinder Specifications
- Model: MD32X60
- Bore size: Ø32 mm
- Stroke: 60 mm
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: 1/4" NPT (G1/8 optional)
- Cushion type: Adjustable rubber buffer
- Mounting style: Basic type (MF1) with 4x M5x0.8 mounting holes
- Rod material: Chrome-plated carbon steel (S45C)
- Cylinder tube: Aluminum alloy (hard anodized)
- Seal material: Nitrile butadiene rubber (NBR)
- Position lock mechanism: Three-stage mechanical locking
- Repeat positioning accuracy: ±0.2 mm
- Max piston speed: 500 mm/s
- Weight: 2.8 kg (with rod)
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H)
- ISO standard: 6432
- Protection rating: IP54
Heavy-duty locking cylinder with precision ground rod and multi-stage position memory. Features wear-resistant anodized barrel and dual anti-rotation guides (keyway & square rod) for stable intermediate stops. Requires filtered air with 5-50μm particulate size and ISO VG32 hydraulic oil lubrication.
- Automated welding fixture positioning
- Press machine tool height adjustment
- Die casting mold core pulling mechanisms
- Automotive assembly line clamping devices
- Packaging machine multi-stage height stops
Installation note:
Maintain 0.05mm maximum misalignment during mounting. Apply silicone-free grease
to rod end before initial operation. Perform lock mechanism maintenance every
500,000 cycles using specified SH-32 locking grease.
| Property | Property Value |
|---|---|
| sku | MD32X60 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | <32 mm> |
| Stroke | 60mm |
