Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X100SCMTC
$47.89
Regular price
$55.39
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MFC20X100SCMTC
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MFC Buffered Stainless Steel Mini Cylinder (AirTAC)
1. Complies with JIS standards;
2. Piston seal adopts a profiled bidirectional sealing structure for compact dimensions and integrated oil reservoir functionality;
3. Fixed shock-absorbing pads on front/rear covers minimize impact during directional changes;
4. Multiple rear cover configurations enhance installation flexibility;
5. Riveted encapsulation structure ensures robust connection between stainless steel cylinder body and covers;
6. High-precision stainless steel tubing offers exceptional strength and corrosion resistance;
7. Compact length design: MF series cylinders are shorter than ISO6432-standard cylinders at identical bore/stroke;
8. Diverse cylinder specifications and mounting accessories available for customized applications.
Category: Stainless Steel Mini Cylinder | Brand: AirTAC | Series: MFC
Maintenance protocol:
Lubricate every 50km of cumulative travel using ISO VG32 turbine oil.
Avoid lateral loading >15N. For vertical mounting, use counterbalance valves.
2. Piston seal adopts a profiled bidirectional sealing structure for compact dimensions and integrated oil reservoir functionality;
3. Fixed shock-absorbing pads on front/rear covers minimize impact during directional changes;
4. Multiple rear cover configurations enhance installation flexibility;
5. Riveted encapsulation structure ensures robust connection between stainless steel cylinder body and covers;
6. High-precision stainless steel tubing offers exceptional strength and corrosion resistance;
7. Compact length design: MF series cylinders are shorter than ISO6432-standard cylinders at identical bore/stroke;
8. Diverse cylinder specifications and mounting accessories available for customized applications.
Category: Stainless Steel Mini Cylinder | Brand: AirTAC | Series: MFC
AirTAC MFC20X100SCMTC Buffered Stainless Steel Mini Cylinder Specifications
- Model: MFC20X100SCMTC
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 100mm (adjustable cushioning ±2mm)
- Operating pressure: 0.05-1.0 MPa (7-145 psi)
- Medium temperature: -20℃ to 80℃ (-4℉ to 176℉)
- Cushion type: Adjustable rubber buffer at both ends
- Port size: M5x0.8 (dual auto switch grooves standard)
- Mounting: Front threaded (M10x1.25) with through-hole option
- Piston speed: 50-750 mm/s (lubricated condition)
- Material:
- Cylinder tube: SUS304 stainless steel
- Piston rod: SUS420 hardened (HRC 45-50)
- Seals: Polyurethane (PU) with wear-resistant coating
- Weight: 0.45kg (with magnetic switch bracket)
- Dimensions: 130mm(L) × 28mm(W) × 28mm(H) (retracted state)
- Protection rating: IP67 (wipers included)
- Certifications: ISO 6431/6432, RoHS compliant
Precision mini cylinder with full stainless steel construction and dual magnetic induction capability. Features shock-absorbing end caps with 3-stage adjustable cushioning (15° rotation per adjustment). Integrated T-slot design allows direct sensor mounting without brackets. Corrosion-resistant for washdown environments.
Typical Applications:
- High-cycle automation: 500,000+ cycles rated
- Cleanroom equipment in semiconductor manufacturing
- Food packaging machinery (NSF-H1 grease compatible)
- Medical device actuation systems
- Robotic end-effector positioning
Maintenance protocol:
Lubricate every 50km of cumulative travel using ISO VG32 turbine oil.
Avoid lateral loading >15N. For vertical mounting, use counterbalance valves.
Performance Data:
Thrust force @0.5MPa: 157N (extend), 133N (retract)
Repeat positioning accuracy: ±0.1mm
Magnetic switch options: D-A73 (2-wire) or D-A93 (3-wire)
Repeat positioning accuracy: ±0.1mm
Magnetic switch options: D-A73 (2-wire) or D-A93 (3-wire)
| Property | Property Value |
|---|---|
| sku | MFC20X100SCMTC |
| Rear Cover Type | Round Type |
| Mounting Type | Center Pivot Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
