Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X105SU
2. Piston seal adopts a profiled bidirectional sealing structure for compact dimensions and integrated oil reservoir functionality;
3. Fixed shock-absorbing pads on front/rear covers minimize impact during directional changes;
4. Multiple rear cover configurations enhance installation flexibility;
5. Riveted encapsulation structure ensures robust connection between stainless steel cylinder body and covers;
6. High-precision stainless steel tubing offers exceptional strength and corrosion resistance;
7. Compact length design: MF series cylinders are shorter than ISO6432-standard cylinders at identical bore/stroke;
8. Diverse cylinder specifications and mounting accessories available for customized applications.
Category: Stainless Steel Mini Cylinder | Brand: AirTAC | Series: MFC
AirTAC MFC20X105SU Stainless Steel Mini Cylinder with Cushion
- Model: MFC20X105SU
- Bore size: 20mm
- Stroke: 105mm
- Material: SUS304 stainless steel (rod/body)
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable rubber buffer (both ends)
- Port size: M5x0.8 (standard) or NPT1/8 optional
- Seal material: NBR + PTFE composite
- Temperature range: -20℃ to 150℃
- Piston speed: 50–800 mm/s (optimal range 100–500 mm/s)
- Rod rotation: Non-rotating design
- Mounting type: Basic (no built-in mounts) with optional accessories
- Weight: 1.23 kg (excluding accessories)
- Dimensions: 215mm(L) × 40mm(W) × 40mm(H) (full extension)
- ISO certification: 6431/DIN ISO 15552 compliant
Precision-engineered compact cylinder featuring corrosion-resistant stainless steel construction and dual-end impact absorption. The chromium-plated piston rod and precision honed tube ensure smooth operation in humid/chemical environments. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4.3 air quality.
- Cleanroom automation in semiconductor manufacturing
- Food packaging machinery (FDA-compliant lubrication)
- Pharmaceutical tablet press mechanisms
- Marine equipment actuators
- High-cycle CNC tool changers (500k+ cycle rating)
Installation guidelines:
Use copper-free anti-seize compound on threaded ports. For vertical mounting,
install speed controller vertically within 300mm of cylinder. Lubricate with
ISO VG32 turbine oil during initial setup.
| Property | Property Value |
|---|---|
| sku | MFC20X105SU |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 105mm |
