Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X10CA
2. Piston seal adopts a profiled bidirectional sealing structure for compact dimensions and integrated oil reservoir functionality;
3. Fixed shock-absorbing pads on front/rear covers minimize impact during directional changes;
4. Multiple rear cover configurations enhance installation flexibility;
5. Riveted encapsulation structure ensures robust connection between stainless steel cylinder body and covers;
6. High-precision stainless steel tubing offers exceptional strength and corrosion resistance;
7. Compact length design: MF series cylinders are shorter than ISO6432-standard cylinders at identical bore/stroke;
8. Diverse cylinder specifications and mounting accessories available for customized applications.
Category: Stainless Steel Mini Cylinder | Brand: AirTAC | Series: MFC
AirTAC MFC20X10CA Buffered Stainless Steel Mini Cylinder Specifications
- Model: MFC20X10CA
- Bore size: 20mm
- Stroke: 10mm
- Buffer type: Adjustable rubber cushion (both ends)
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -20℃ to 80℃
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Mounting type: Basic foot mounting (MF series standard)
- Cylinder material: SUS304 stainless steel
- Rod material: SUS304 stainless steel
- Seal material: NBR (standard) / FKM (optional)
- Piston speed: 50–700 mm/s
- Weight: 0.35kg (without accessories)
- Dimensions:
- Body length: 68mm
- Extended length: 78mm (stroke included)
- Width: 30mm (mounting base)
- Height: 32mm (cylinder diameter)
- ISO standard: 6432 compliant
- Protection rating: IP67
Compact stainless steel cylinder with corrosion-resistant construction and dual cushioning system. Features precision honed tube (Ra≤0.4μm) for smooth operation and reduced wear. The MFC series' space-saving design (20% smaller than standard ISO cylinders) enables integration in robotic grippers and confined spaces. Includes built-in auto switch grooves for sensor mounting.
- Cleanroom automation in semiconductor manufacturing
- Food processing machinery (corrosion-resistant variant)
- Medical device actuation systems
- High-cycle PCB component insertion machines
- Pharmaceutical packaging lines
- Marine equipment controls (saltwater environment)
Operation note:
Lubricate with ISO VG32 hydraulic oil for initial use.
Maintain 0.3-1.0 MPa operating pressure for optimal cushioning performance.
Avoid side load exceeding 5N during installation.
| Property | Property Value |
|---|---|
| sku | MFC20X10CA |
| Rear Cover Type | Swivel Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
