Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X10UTC
2. Piston seal adopts a profiled bidirectional sealing structure for compact dimensions and integrated oil reservoir functionality;
3. Fixed shock-absorbing pads on front/rear covers minimize impact during directional changes;
4. Multiple rear cover configurations enhance installation flexibility;
5. Riveted encapsulation structure ensures robust connection between stainless steel cylinder body and covers;
6. High-precision stainless steel tubing offers exceptional strength and corrosion resistance;
7. Compact length design: MF series cylinders are shorter than ISO6432-standard cylinders at identical bore/stroke;
8. Diverse cylinder specifications and mounting accessories available for customized applications.
Category: Stainless Steel Mini Cylinder | Brand: AirTAC | Series: MFC
AirTAC MFC Series Cushioned Stainless Steel Mini Cylinder MFC20X10UTC Specifications
- Model: MFC20X10UTC
- Bore size: 20mm
- Stroke: 10mm (±1mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Cushioning type: Adjustable air cushion (dual-side)
- Material: SUS304 stainless steel body, NBR seals
- Operating temperature: -20℃ to 80℃
- Port size: M5×0.8 (1/8")
- Mounting type: Basic front flange (optional side/axial mounts)
- Piston speed: 50–800 mm/s
- Weight: 0.25kg (excluding accessories)
- Dimensions: 65mm(L) × 24mm(W) × 24mm(H) (retracted position)
- Rod thread: M6×1.0
- Protection rating: IP67 (dust/water resistant)
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if maintained)
Ultra-compact stainless steel cylinder with precision-machined air cushion mechanism, designed for corrosive environments and cleanroom applications. Features non-rotating piston rod and anti-vibration design for high positional accuracy. Requires 40μm filtered air with dew point below -10℃.
- Medical device actuation systems
- Food processing equipment (NSF compliant)
- Semiconductor wafer handling robots
- Pharmaceutical tablet press machines
- Marine instrumentation controls
Installation tip:
Apply thread lock (medium strength) to mounting screws and maintain 0.5mm
clearance between rod end and load during alignment. Perform 50-100 no-load
cycles before full operation.
| Property | Property Value |
|---|---|
| sku | MFC20X10UTC |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Center Pivot Bracket |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | <10mm> |
