Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X115U
$39.30
Regular price
$46.80
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MFC20X115U
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MFC Buffered Stainless Steel Mini Cylinder (AirTAC)
1. Complies with JIS standards;
2. Piston seal adopts a profiled bidirectional sealing structure for compact dimensions and integrated oil reservoir functionality;
3. Fixed shock-absorbing pads on front/rear covers minimize impact during directional changes;
4. Multiple rear cover configurations enhance installation flexibility;
5. Riveted encapsulation structure ensures robust connection between stainless steel cylinder body and covers;
6. High-precision stainless steel tubing offers exceptional strength and corrosion resistance;
7. Compact length design: MF series cylinders are shorter than ISO6432-standard cylinders at identical bore/stroke;
8. Diverse cylinder specifications and mounting accessories available for customized applications.
Category: Stainless Steel Mini Cylinder | Brand: AirTAC | Series: MFC
Installation guidelines:
Use stainless steel fasteners for corrosion resistance matching.
Adjust cushion screws clockwise to increase damping force (1/4 turn increments).
Lubricate with ISO VG32 hydraulic oil if used below -10℃.
Maximum side load: 15N at rod end.
2. Piston seal adopts a profiled bidirectional sealing structure for compact dimensions and integrated oil reservoir functionality;
3. Fixed shock-absorbing pads on front/rear covers minimize impact during directional changes;
4. Multiple rear cover configurations enhance installation flexibility;
5. Riveted encapsulation structure ensures robust connection between stainless steel cylinder body and covers;
6. High-precision stainless steel tubing offers exceptional strength and corrosion resistance;
7. Compact length design: MF series cylinders are shorter than ISO6432-standard cylinders at identical bore/stroke;
8. Diverse cylinder specifications and mounting accessories available for customized applications.
Category: Stainless Steel Mini Cylinder | Brand: AirTAC | Series: MFC
AirTAC MFC Series Stainless Steel Mini Cylinder with Cushioning MFC20X115U
- Model: MFC20X115U
- Series: MFC (Compact Stainless Steel)
- Bore size: 20mm
- Stroke: 115mm
- Material: Stainless steel cylinder body & piston rod
- Seal material: NBR (Nitrile rubber) with wear-resistant design
- Cushioning type: Adjustable air cushioning at both ends
- Mounting style: Front flange (MF1), rear flange (MF2), or foot mounting (MF3)
- Operating pressure: 0.05–1.0 MPa (7-145 psi)
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Port size: G1/8 (ISO standard)
- Cushion adjustment: 360° rotatable adjustment screws
- Piston speed: 50–800 mm/s (optimal range)
- Protection rating: IP67 (dust-tight & temporary immersion)
- Weight: 1.25 kg (2.76 lbs) ±2%
- Dimensions:
- Total length (extended): 200mm
- Cylinder diameter: 20mm (body), 32mm (flange)
- Mounting hole spacing: 32mm × 32mm (square pattern)
- Rod end thread: M10×1.25 (male)
Premium corrosion-resistant mini cylinder featuring triple-chamber cushioning technology for ultra-smooth deceleration. The full stainless steel construction enables operation in humid/chemical environments while maintaining ±0.5mm repeat positioning accuracy. Integrated shock absorbers reduce end-impact noise by 15dB compared to standard models.
Ideal Applications:
- Food processing equipment (washdown environments)
- Pharmaceutical tablet pressing machines
- PCB handling robots in electronics manufacturing
- Precision clamping in optical lens production
- Cleanroom automation systems (Class 1000 or better)
- Packaging line pusher mechanisms
Installation guidelines:
Use stainless steel fasteners for corrosion resistance matching.
Adjust cushion screws clockwise to increase damping force (1/4 turn increments).
Lubricate with ISO VG32 hydraulic oil if used below -10℃.
Maximum side load: 15N at rod end.
Lubrication:
Pre-lubricated for life – do not disassemble seals.
For heavy cycling (>500,000 cycles/year), apply light coating of PAG grease annually.
| Property | Property Value |
|---|---|
| sku | MFC20X115U |
| Rear Cover Type | Flat Tail Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 115mm |
