Airtac MFC Cushioned Stainless Steel Mini Cylinder MFC20X125SCM
2. Piston seal adopts a profiled bidirectional sealing structure for compact dimensions and integrated oil reservoir functionality;
3. Fixed shock-absorbing pads on front/rear covers minimize impact during directional changes;
4. Multiple rear cover configurations enhance installation flexibility;
5. Riveted encapsulation structure ensures robust connection between stainless steel cylinder body and covers;
6. High-precision stainless steel tubing offers exceptional strength and corrosion resistance;
7. Compact length design: MF series cylinders are shorter than ISO6432-standard cylinders at identical bore/stroke;
8. Diverse cylinder specifications and mounting accessories available for customized applications.
Category: Stainless Steel Mini Cylinder | Brand: AirTAC | Series: MFC
AirTAC MFC20X125SCM Cushioned Stainless Steel Mini Cylinder Specifications
- Model: MFC20X125SCM
- Bore size: 20mm
- Stroke: 125mm
- Cushion type: Adjustable rubber buffer (both ends)
- Material: Stainless steel (SUS304 barrel, CR12MOV piston rod)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -10℃ to 150℃
- Port size: M5×0.8 (dual ports)
- Mounting type: Basic foot mounting (ISO 6432 standard)
- Piston speed: 50–800 mm/s
- Protection rating: IP67 (wipers included)
- Weight: 0.68 kg (with accessories)
- Dimensions: 180mm(L) × 34mm(W) × 34mm(H) (fully extended)
- Lubrication: Pre-lubricated (use ISO VG32 or equivalent)
- Repeat positioning accuracy: ±0.2mm
- Accessories: Magnetic piston standard (for sensor integration)
Precision-engineered mini cylinder with corrosion-resistant stainless steel construction and dual cushioning system. Features a compact profile with high rigidity piston rod for stable linear motion in space-constrained applications. The integrated buffer mechanism reduces end-impact noise to 65dB(A) while maintaining 1,500km minimum service life.
- Semiconductor wafer handling robots
- Medical device actuation systems
- High-cycle packaging machinery
- Cleanroom automation (FDA-compliant seals)
- Precision dosing/pipetting equipment
- Automotive test bench fixtures
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load. For vertical mounting,
use counterbalance valves. Lubricate every 3 months in normal operation (every
1,000km stroke). Avoid side loads exceeding 15N.
| Property | Property Value |
|---|---|
| sku | MFC20X125SCM |
| Rear Cover Type | Round Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
