Airtac MFCJ Adjustable Mini Cylinder MFCJ20X100-100
1. Complies with JIS standards;
2. Features an asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication;
3. Integrated shock-absorbing pads on end caps reduce impact during directional changes;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped clamping mechanism between stainless steel barrel and end caps ensures secure connection;
6. High-precision stainless steel cylinder tube provides excellent strength and corrosion resistance;
7. Compact design offers shorter overall length than ISO 6432 standard cylinders with equivalent bore and stroke;
8. Comprehensive range of cylinder sizes and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: MFCJ
AirTAC MFCJ Adjustable Miniature Cylinder MFCJ20X100-100 Technical Details
- Model Code: MFCJ20X100-100
- Bore Size: 20mm (ISO 6432 standard)
- Stroke: 100mm (±0.5mm tolerance)
- Adjustment Range: 0-10mm (via external stroke adjustment screws)
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Cushion Type: Rubber buffer + adjustable hydraulic absorber
- Port Size: M5x0.8 (standard) with G1/8 adaptor optional
- Piston Speed: 50-750 mm/s (lubricated condition)
- Mounting Types: Basic (no mount) with optional foot/mid-flange
- Rod Thread: M6x1.0 external thread (stainless steel)
- Body Material: Anodized aluminum alloy (black oxide finish)
- Seal Material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Weight: 0.62kg (excluding accessories)
- Dimensions:
- Extended Length: 187mm
- Retracted Length: 87mm
- Body Diameter: 32mm
- Mounting Hole Spacing: 25mm (center-to-center)
Ultra-compact cylinder featuring dual-axis stroke adjustment mechanism with locking nuts, designed for precision positioning in confined spaces. The integrated hydraulic cushion prevents end-impact noise (<65dB) while maintaining positioning accuracy within ±0.2mm. Includes built-in magnet for magnetic sensor compatibility (PNP/NPN types). Requires ISO 8573-1 class 3 filtered air with 1-5μm lubricator for optimal performance.
- PCB handling robots - component insertion/removal
- Pharmaceutical tablet pressing mechanisms
- Automated optical inspection (AOI) positioning stages
- Beverage canning line lid alignment systems
- Semiconductor wafer transfer actuators
Installation Protocol:
For vertical installations exceeding 45° angle, use counterbalance valves.
Maintain 0.5mm minimum clearance between adjustment screws and mechanical stops during calibration.
Lubricate every 500,000 cycles with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | MFCJ20X100-100 |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
