Airtac MFCJ Adjustable Mini Cylinder MFCJ20X100-30S
1. Complies with JIS standards;
2. Features an asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication;
3. Integrated shock-absorbing pads on end caps reduce impact during directional changes;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped clamping mechanism between stainless steel barrel and end caps ensures secure connection;
6. High-precision stainless steel cylinder tube provides excellent strength and corrosion resistance;
7. Compact design offers shorter overall length than ISO 6432 standard cylinders with equivalent bore and stroke;
8. Comprehensive range of cylinder sizes and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: MFCJ
AirTAC MFCJ20X100-30S Adjustable Mini Cylinder Specifications
- Model: MFCJ20X100-30S
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 100mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting style: Basic foot mount (ISO 15552 accessory compatible)
- Port size: M5×0.8 (standard) with NPT1/8 optional
- Piston rod thread: M10×1.25
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (nitrile rubber)
- Weight: 380g ±2% (without accessories)
- Dimensions:
- Length: 166mm (fully retracted)
- Width: 32mm (mounting base width)
- Height: 42mm (including piston rod protrusion)
Ultra-compact pneumatic cylinder featuring precision-machined components and dual adjustable cushioning for smooth end-of-stroke deceleration. The corrosion-resistant design incorporates an anodized aluminum body with chrome-plated piston rod, optimized for high-cycle operations. Requires 40μm filtered air and ISO VG32 hydraulic oil lubrication (optional oil-free operation).
- PCB handling robots in semiconductor manufacturing
- Precision clamping devices in CNC tool changers
- Medical device assembly automation
- Compact packaging machine actuators
- Laboratory sample positioning systems
Installation note:
Adjust cushion screws in 1/4-turn increments during commissioning.
Maintain ≥3mm clearance from adjacent components for heat dissipation.
Lubricate every 500,000 cycles under normal load conditions.
Avoid side load exceeding 15N.
For vertical mounting, use guided rail kits (sold separately)
when payload exceeds 2kg to prevent piston rod bending.
| Property | Property Value |
|---|---|
| sku | MFCJ20X100-30S |
| Adjustable Stroke | 30mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
