Airtac MFCJ Adjustable Mini Cylinder MFCJ20X100-50
1. Complies with JIS standards;
2. Features an asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication;
3. Integrated shock-absorbing pads on end caps reduce impact during directional changes;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped clamping mechanism between stainless steel barrel and end caps ensures secure connection;
6. High-precision stainless steel cylinder tube provides excellent strength and corrosion resistance;
7. Compact design offers shorter overall length than ISO 6432 standard cylinders with equivalent bore and stroke;
8. Comprehensive range of cylinder sizes and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: MFCJ
AirTAC MFCJ20X100-50 Adjustable Mini Cylinder Specifications
- Model: MFCJ20X100-50
- Type: Double-acting adjustable cushioning cylinder
- Bore size: Ø20mm (±0.1mm tolerance)
- Stroke: 100mm (adjustable via cushion screws)
- Operating pressure: 0.05–1.0 MPa
- Port size: M5×0.8 (dual ports)
- Cushion type: External adjustable (both ends)
- Mounting style: Basic type (no foot)
- Temperature range: -10℃ to 80℃
- Cylinder material: Aluminum alloy barrel (A6063-T5)
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR (nitrile rubber)
- Weight: 620g ±5% (with rod)
- Dimensions:
- Length: 165mm (full retracted)
- Stroke-adjusted length: 100±0.5mm
- Body diameter: Ø32mm
- Mounting hole spacing: 25mm (center-to-center)
Ultra-compact cylinder featuring dual-side shock absorption adjustment with ±30° cushion screw rotation range. Precision-ground rod (Ra0.4μm finish) ensures low friction operation. Includes built-in magnet for position sensing compatibility. Rated for 5,000km service life under standard conditions (0.5MPa, 20℃).
- PCB handling robots with limited space
- Pharmaceutical blister packaging machines
- Semiconductor wafer transfer mechanisms
- Automated microscope stage positioning
- Compact assembly jigs requiring precise end-stop control
Installation note:
Use C-shaped mounting brackets (sold separately) for vibration-prone environments.
Lubricate with ISO VG32 hydraulic oil before initial use. Maintain 0.3mm minimum
lateral clearance during alignment.
| Property | Property Value |
|---|---|
| sku | MFCJ20X100-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
