Airtac MFCJ Adjustable Mini Cylinder MFCJ20X100-75
1. Complies with JIS standards;
2. Features an asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication;
3. Integrated shock-absorbing pads on end caps reduce impact during directional changes;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped clamping mechanism between stainless steel barrel and end caps ensures secure connection;
6. High-precision stainless steel cylinder tube provides excellent strength and corrosion resistance;
7. Compact design offers shorter overall length than ISO 6432 standard cylinders with equivalent bore and stroke;
8. Comprehensive range of cylinder sizes and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: MFCJ
AirTAC MFCJ20X100-75 Adjustable Miniature Cylinder Specifications
- Model: MFCJ20X100-75
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: 20mm
- Stroke: 100mm
- Adjustment range: 0-75% stroke cushioning (mechanical stopper)
- Operating pressure: 0.05–1.0 MPa
- Ambient temperature: -10℃ to 70℃
- Piston speed: 50–800 mm/s
- Port size: M5x0.8 (standard) / NPT1/8 optional
- Mounting type: Basic (no foot) with 2x M4 threaded holes
- Cushion type: Adjustable rubber buffers (both ends)
- Seal material: NBR (standard) / FKM optional
- Piston rod material: Stainless steel (SUS304)
- Weight: 340g ±5% (without accessories)
- Dimensions:
- Total length (retracted): 148mm
- Body diameter: 28mm
- Rod end thread: M6x1.0
- Mounting hole spacing: 25mm (longitudinal)
- Protection rating: IP54 (standard) / IP67 with optional wiper
Ultra-compact cylinder with precision stroke adjustment capability, featuring a space-saving design 35% smaller than standard cylinders. The dual-cushion mechanism allows fine-tuning of end-position deceleration via screw-type adjusters. Anodized aluminum construction resists chemical corrosion in industrial environments. Compatible with ISO 6432 mounting accessories.
- PCB handling robots requiring precise positioning
- Medical device actuators with limited installation space
- Semiconductor wafer clamping mechanisms
- Packaging machine ejector systems
- Laboratory automation linear motion control
Maintenance tip:
Lubricate every 500,000 cycles using ISO VG32 turbine oil. Avoid lateral
force exceeding 15N on piston rod. For vertical mounting, use locknut
(ASNU6) to prevent position drift.
| Property | Property Value |
|---|---|
| sku | MFCJ20X100-75 |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
