Airtac MFCJ Adjustable Mini Cylinder MFCJ20X100-75S
1. Complies with JIS standards;
2. Features an asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication;
3. Integrated shock-absorbing pads on end caps reduce impact during directional changes;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped clamping mechanism between stainless steel barrel and end caps ensures secure connection;
6. High-precision stainless steel cylinder tube provides excellent strength and corrosion resistance;
7. Compact design offers shorter overall length than ISO 6432 standard cylinders with equivalent bore and stroke;
8. Comprehensive range of cylinder sizes and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: MFCJ
AirTAC MFCJ20X100-75S Adjustable Miniature Cylinder Specifications
- Model: MFCJ20X100-75S
- Bore size: 20mm
- Stroke: 100mm (±0.5mm adjustment range)
- Operating pressure: 0.05–0.9 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning type: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (axial foot mounting)
- Port size: Rc1/8 (PT1/8 equivalent)
- Piston rod thread: M6×1.0
- Material: Aluminum alloy body (anodized), CR12MoV piston rod
- Seal material: NBR + polyurethane hybrid seals
- Protection rating: IP54 (standard)
- Weight: 0.75kg (excluding accessories)
- Dimensions: 200mm(L) × 40mm(W) × 40mm(H) (full extension)
Ultra-compact pneumatic cylinder featuring precision stroke adjustment via built-in locking nuts (±0.5mm fine-tuning). The corrosion-resistant design incorporates dual cushioning buffers with 5-stage impact absorption, making it ideal for high-cycle applications. Requires ISO 8573-1:2010 [4:4:3] class compressed air.
- PCB handling robots in electronics assembly
- Precision clamping mechanisms for CNC tool changers
- Medical device actuator systems
- Automated cosmetic packaging lines
- Semiconductor wafer positioning stages
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial operation.
For vertical mounting, add 15% extra thrust margin.
Maximum side load capacity: 12N at full extension.
| Property | Property Value |
|---|---|
| sku | MFCJ20X100-75S |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
