Airtac MFCJ Adjustable Mini Cylinder MFCJ20X110-20S
1. Complies with JIS standards;
2. Features an asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication;
3. Integrated shock-absorbing pads on end caps reduce impact during directional changes;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped clamping mechanism between stainless steel barrel and end caps ensures secure connection;
6. High-precision stainless steel cylinder tube provides excellent strength and corrosion resistance;
7. Compact design offers shorter overall length than ISO 6432 standard cylinders with equivalent bore and stroke;
8. Comprehensive range of cylinder sizes and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: MFCJ
AirTAC MFCJ Adjustable Miniature Cylinder MFCJ20X110-20S Technical Details
- Model: MFCJ20X110-20S
- Type: Double-acting adjustable cushion cylinder
- Bore size: 20mm
- Stroke: 110mm (±0.5mm tolerance)
- Operating pressure: 0.05-1.0 MPa
- Cushion type: External adjustable rubber bumper (both ends)
- Mounting style: Basic foot mounting (ISO 15552 compatible)
- Port size: M5×0.8 (Standard) with G1/8 adaptor option
- Piston rod thread: M10×1.25
- Operating temperature: -10℃ to 80℃
- Material:
- Tube: Anodized aluminum alloy
- Piston rod: Chrome-plated steel
- Seals: NBR (Nitrile rubber)
- Protection class: IP54 (standard sealing)
- Weight: 0.72kg (including accessories)
- Dimensions:
- Extended length: 210mm (stroke 110 + body 100)
- Body width: 34mm (max. profile dimension)
- Height with rod: 48mm (from base to rod centerline)
Ultra-compact cylinder (42% smaller than standard ISO cylinders) featuring precision-ground rod and dual anti-rotation design. The adjustable cushion mechanism allows 1/4-turn fine-tuning of end-position damping (adjustment range: 0-5mm). Pre-lubricated for maintenance-free operation with ISO VG32 hydraulic oil. Requires 40μm filtered dry air with ≤1g/m³ oil mist content.
- PCB handling robots in electronics manufacturing
- Precision clamping fixtures for CNC machining
- Thread cutting automation in textile machinery
- Medical device assembly systems
- Packaging machine feed mechanisms
Installation guidelines:
Maximum side load capacity 15N. For vertical mounting,
maintain rod-end-down orientation. Use locknuts (not included)
with 18-22N·m torque for mounting bracket fixation.
| Property | Property Value |
|---|---|
| sku | MFCJ20X110-20S |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 110mm |
