Airtac MFCJ Adjustable Mini Cylinder MFCJ20X120-20S
1. Complies with JIS standards;
2. Features an asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication;
3. Integrated shock-absorbing pads on end caps reduce impact during directional changes;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped clamping mechanism between stainless steel barrel and end caps ensures secure connection;
6. High-precision stainless steel cylinder tube provides excellent strength and corrosion resistance;
7. Compact design offers shorter overall length than ISO 6432 standard cylinders with equivalent bore and stroke;
8. Comprehensive range of cylinder sizes and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: MFCJ
AirTAC MFCJ20X120-20S Adjustable Mini Cylinder Specifications
- Model: MFCJ20X120-20S
- Type: Double-acting adjustable stroke mini cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 120mm (±1mm adjustable)
- Operating pressure: 0.05-1.0 MPa
- Port size: M5x0.8 (dual ports at both ends)
- Cushioning type: Adjustable rubber buffer
- Mounting style: Front flange (standard), optional rear threaded
- Temperature range: -10℃ to 80℃
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Weight: 520g ±3% (without accessories)
- Dimensions: 160mm(L) × 34mm(W) × 34mm(H) (retracted position)
- Max piston speed: 500mm/s
- Lubrication: Pre-lubricated (DOP-free grease)
- Protection rating: IP54 (standard), IP67 optional
Ultra-compact linear actuator with precision stroke adjustment, featuring dual-position sensing slots for magnetic switch installation (SN/-S series switches compatible). The stepped piston rod design enhances lateral load capacity by 30% compared to standard mini cylinders. Includes auto-locking stroke adjustment mechanism with ±1mm repeatability.
- PCB handling robots in electronics assembly
- Precision clamping devices for CNC tooling
- Dispensing equipment valve actuators
- Compact packaging machine pushers
- Medical device positioning mechanisms
- Automated test equipment sample handlers
Installation notes:
For optimal performance, maintain ≤0.3mm misalignment tolerance during mounting.
Use locknut (model MFAL20) for threaded rod end fixation. Lubricate every 500km stroke
movement with ISO VG32 turbine oil. Avoid side load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | MFCJ20X120-20S |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 120mm |
