Airtac MFCJ Adjustable Mini Cylinder MFCJ20X125-10
$54.19
Regular price
$61.69
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MFCJ20X125-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
MFCJ Adjustable Miniature Cylinder
1. Complies with JIS standards;
2. Features an asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication;
3. Integrated shock-absorbing pads on end caps reduce impact during directional changes;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped clamping mechanism between stainless steel barrel and end caps ensures secure connection;
6. High-precision stainless steel cylinder tube provides excellent strength and corrosion resistance;
7. Compact design offers shorter overall length than ISO 6432 standard cylinders with equivalent bore and stroke;
8. Comprehensive range of cylinder sizes and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: MFCJ
Installation tips:
For vertical mounting, reduce max speed by 30%. Adjust cushion screws in 1/4 turn increments during commissioning.
Requires 5μm filtered air with 1-10mg/m³ oil mist. Annual seal replacement recommended in high-cycle (>1M/yr) applications.
1. Complies with JIS standards;
2. Features an asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication;
3. Integrated shock-absorbing pads on end caps reduce impact during directional changes;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped clamping mechanism between stainless steel barrel and end caps ensures secure connection;
6. High-precision stainless steel cylinder tube provides excellent strength and corrosion resistance;
7. Compact design offers shorter overall length than ISO 6432 standard cylinders with equivalent bore and stroke;
8. Comprehensive range of cylinder sizes and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: MFCJ
AirTAC MFCJ20X125-10 Adjustable Mini Cylinder Specifications
- Model: MFCJ20X125-10
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: Ø20mm (ISO 6432 standard)
- Stroke: 125mm (customizable 25-300mm)
- Thread port size: M5×0.8 (G1/8 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushion type: External adjustable rubber bumper
- Piston speed: 50–700 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: Nitrile rubber (NBR) standard (Polyurethane available)
- Weight: 0.45kg (with standard accessories)
- Dimensions: 160mm(L) × 40mm(W) × 40mm(H) (stroke extended)
- Rod thread: M6×1.0 male thread
- Mounting type: Basic (no foot) with axial mounting holes
- Lubrication: Pre-lubricated (use ISO VG32 turbine oil if needed)
Ultra-compact cylinder featuring space-saving design with 22% smaller cross-section than standard models. The dual adjustable cushions reduce end-impact noise to ≤75dB. Precision honed tube ensures ≤0.8μm surface roughness for smooth operation. Optional magnetic piston version (suffix -M) available for position sensing.
Typical Applications:
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Precision lens positioning in optical equipment
- Automated test fixture actuation
- Cleanroom-compatible medical devices
- Textile machine thread tension control
Installation tips:
For vertical mounting, reduce max speed by 30%. Adjust cushion screws in 1/4 turn increments during commissioning.
Requires 5μm filtered air with 1-10mg/m³ oil mist. Annual seal replacement recommended in high-cycle (>1M/yr) applications.
| Property | Property Value |
|---|---|
| sku | MFCJ20X125-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
