Airtac MFCJ Adjustable Mini Cylinder MFCJ20X125-40
1. Complies with JIS standards;
2. Features an asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication;
3. Integrated shock-absorbing pads on end caps reduce impact during directional changes;
4. Multiple rear cover configurations for enhanced installation flexibility;
5. Crimped clamping mechanism between stainless steel barrel and end caps ensures secure connection;
6. High-precision stainless steel cylinder tube provides excellent strength and corrosion resistance;
7. Compact design offers shorter overall length than ISO 6432 standard cylinders with equivalent bore and stroke;
8. Comprehensive range of cylinder sizes and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AIRTAC | Series: MFCJ
AirTAC MFCJ20X125-40 Adjustable Mini Cylinder Technical Details
- Model: MFCJ20X125-40
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 125mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Cushioning type: Adjustable pneumatic cushion (dual-side)
- Port size: M5×0.8 (G1/8 adaptor optional)
- Piston speed: 50–800 mm/s (lubricated condition)
- Ambient temperature: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel (SUS304)
- Seals: NBR + PU combination
- Weight: 820g ±2% (including standard accessories)
- Dimensions:
- Extended length: 255mm (stroke + cylinder base length)
- Retracted length: 130mm
- Body width: 48mm (mounting face to face)
- Height with rod: 62mm (from centerline)
- Mounting type: MF series standard (optional foot/ flange mounts)
- Position detection: Built-in magnet (D-M9N sensor compatible)
Ultra-compact cylinder with precision stroke adjustment mechanism, featuring dual cushion control knobs for smooth end-position damping. The anti-rotation piston rod design ensures stable linear motion, while the modular structure allows easy integration with ISO 6432-compliant accessories. Requires ISO VG32 hydraulic oil mist lubrication (0.1cm³/min minimum).
- PCB handling robots in electronics assembly
- Precision dosing valves in pharmaceutical equipment
- Label application mechanisms in packaging lines
- Micro-positioning stages in optical alignment systems
- Vending machine product pushers
Installation guidelines:
Maintain 0.5mm minimum clearance between rod end and load during alignment.
For vertical mounting, use locknut (ASNU05-20) to prevent stroke drift.
Lubricate through air supply (1–2 drops oil/m³ air) for optimal seal life.
| Property | Property Value |
|---|---|
| sku | MFCJ20X125-40 |
| Adjustable Stroke | <40mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
