Airtac MFJ Adjustable Mini Cylinder MFJ20X100-10
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X100-10 Technical Details
- Model: MFJ20X100-10
- Type: Double-acting adjustable cushioning cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 100mm (customizable 50-300mm)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable rubber buffers (both ends)
- Port size: M5x0.8 (dual ports at both ends)
- Mounting: Front flange (standard), optional side/axial mounts
- Temperature range: -20℃ to 80℃
- Seal material: Nitrile Butadiene Rubber (NBR)
- Repeat positioning accuracy: ±0.5mm
- Max piston speed: 500 mm/s
- Weight: 0.68 kg (with standard fittings)
- Dimensions:
- Extended length: 189mm
- Retracted length: 89mm
- Body width: 34mm
- Mounting height: 20mm
Ultra-compact ISO-compliant pneumatic cylinder featuring precision-machined aluminum body with hard anodized finish. The dual adjustable cushioning system minimizes end-impact noise while allowing precise stroke-end velocity control. Integrated mounting slots enable tool-free position adjustment in confined spaces. Compatible with all standard 20mm cylinder accessories.
- PCB handling robots in electronics manufacturing
- Pharmaceutical blister packaging machines
- Micro-positioning in optical lens assembly
- Automated test equipment actuator
- Compact clamping fixtures for CNC workholding
Installation recommendation:
For vertical installations exceeding 0.6MPa pressure, use external guides. Lubricate through air supply (ISO VG32 equivalent oil mist) for optimal seal life. Avoid side-load exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | MFJ20X100-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
