Airtac MFJ Adjustable Mini Cylinder MFJ20X100-100
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X100-100 Specifications
- Model: MFJ20X100-100
- Bore size: 20 mm
- Stroke: 100 mm
- Action type: Double-acting
- Operating pressure: 0.15–1.0 MPa
- Cushion type: Adjustable air cushion (both ends)
- Port size: M5x0.8 (standard) / G1/8 optional
- Piston speed: 50–750 mm/s
- Ambient temperature: -20℃ to 80℃
- Seal material: NBR (standard) / PU optional
- Body material: Anodized aluminum alloy
- Rod material: Stainless steel (SUS304)
- Weight: 0.62 kg ±3%
- Dimensions (L×W×H): 164mm × 34mm × 34mm (extended length: 264mm)
- Mounting options: Basic type (axial mounting holes) + accessory brackets
- Position detection: Built-in magnet for sensor mounting
- ISO standard: Compliant with ISO 6432 (miniature series)
Ultra-compact cylinder with precision-adjustable cushioning, designed for space-constrained automation systems. Features corrosion-resistant construction and dual anti-rotation guides for stable linear motion. The chrome-plated piston rod integrates wear-resistant seals, supporting 2 million cycles at rated pressure. Requires 5μm filtered lubricated air (ISO 8573-1 class 5).
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms for CNC tooling
- Lab automation sample positioning systems
- Pharmaceutical blister packaging machines
- Semiconductor wafer transfer units
Installation tips:
(1) Align mounting surface flatness within 0.2mm/m
(2) Adjust cushion screws clockwise to increase damping force
(3) Lubricate every 3 months with ISO VG32 turbine oil
(4) Avoid side loads exceeding 15N
| Property | Property Value |
|---|---|
| sku | MFJ20X100-100 |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
