Airtac MFJ Adjustable Mini Cylinder MFJ20X100-10S
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ20X100-10S Adjustable Mini Cylinder Technical Details
- Series: MFJ (Compact Adjustable Stroke)
- Bore size: 20mm
- Stroke: 100mm ±1.5mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Ambient temperature: -10℃ to 60℃
- Cushioning: Adjustable rubber buffer (both ends)
- Port size: M5×0.8 (standard) / NPT1/8 optional
- Piston speed: 50-700 mm/s
- Action type: Double-acting
- Rod thread: M6×1.0
- Body material: Aluminum alloy (anodized)
- Seal material: NBR (nitrile rubber)
- Weight: 520g ±3%
- Dimensions: 155mm(L) × 34mm(W) × 34mm(H) (fully retracted)
- Mounting options: Female thread (standard), optional foot/male/front flange
- ISO standard: 6432 compliant
Ultra-compact pneumatic cylinder featuring micrometer-style stroke adjustment (±1.5mm) via hex wrench for precision positioning. The dual adjustable cushioning system minimizes end-impact noise below 70dB(A). Anti-rotation design with integrated guide slots ensures stable linear motion. Compatible with ISO 6432 mounting accessories.
- PCB handling robots - component insertion/removal
- Pharmaceutical blister packaging machines
- Semiconductor wafer transfer mechanisms
- Automated test equipment (ATE) probe positioning
- Food processing portion control gates
Maintenance tip:
Lubricate with ISO VG32 turbine oil every 500km stroke travel.
Avoid side loads exceeding 3N·m. For vertical mounting,
use locking nut (AN20-M6 accessory) to prevent stroke drift.
| Property | Property Value |
|---|---|
| sku | MFJ20X100-10S |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
