Airtac MFJ Adjustable Mini Cylinder MFJ20X100-20S
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X100-20S Specifications
- Model: MFJ20X100-20S
- Type: Double-acting adjustable cushion mini cylinder
- Bore size: 20mm
- Stroke: 100mm (±0.5mm tolerance)
- Mounting style: Standard foot + front flange (dual mounting)
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Adjustable rubber bumper (both ends)
- Port size: M5x0.8 (standard) or NPT1/8 (optional)
- Piston speed: 50–800 mm/s (lubricated condition)
- Ambient temperature: -10℃ to 80℃
- Seal material: NBR (standard), optional Polyurethane for high-speed applications
- Weight: 0.8kg (including accessories)
- Dimensions:
- Extended length: 184mm
- Retracted length: 84mm
- Body diameter: 32mm
- Mounting hole spacing: 25mm (front flange), 30mm (foot mount)
Ultra-compact cylinder featuring precision-machined aluminum alloy construction with hard anodized finish. The dual adjustable cushion mechanism minimizes impact noise while allowing stroke-end velocity optimization. Integrated mounting grooves enable tool-free position adjustment, and the corrosion-resistant design supports operation in humid environments. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- PCB handling robots in electronics manufacturing
- Precision clamping fixtures for CNC machining centers
- Medical device assembly automation
- Packaging machine ejector systems
- Semiconductor wafer positioning mechanisms
Installation tip:
For vertical installations exceeding 0.7 MPa, use the auxiliary rod-end support (ASMFJ-20 accessory recommended).
Lubricate with ISO VG32 turbine oil for high-cycle applications (>5 million cycles).
| Property | Property Value |
|---|---|
| sku | MFJ20X100-20S |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
