Airtac MFJ Adjustable Mini Cylinder MFJ20X100-50
$41.63
Regular price
$49.13
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MFJ20X100-50
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JS standards;
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
Installation note:
For optimal performance, maintain 0.5-1mm clearance between adjustable stoppers and cylinder body during stroke setting. Lubricate with ISO VG32 hydraulic oil if used in high-cycle (>5Hz) applications.
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ20X100-50 Adjustable Miniature Cylinder Specifications
- Model: MFJ20X100-50
- Type: Double-acting adjustable stroke cylinder
- Bore size: 20 mm
- Stroke: 100 mm (adjustable)
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Basic type (Standard) with optional foot/mid-mount brackets
- Port size: M5x0.8 (PT1/8 adapter available)
- Material: Aluminum barrel, chrome-plated steel piston rod
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 0.75 kg (unlubricated)
- Dimensions: 150mm(L) × 34mm(W) × 34mm(H) (at full extension)
- Rod thread: M6x1 external thread at both ends
- Max theoretical force: 28.3 kgf @0.5 MPa
- ISO standard: Compliant with ISO 6432 (miniature cylinders)
A space-saving linear actuator featuring tool-free stroke adjustment via rotating end caps (±5mm fine-tuning range). Precision-machined guide bush prevents rotation during operation. Optional magnetic piston version (add "-M" suffix) for position sensing compatibility.
Typical Applications:
- PCB handling robots in electronics assembly
- Dispenser head positioning in adhesive applications
- Lab automation equipment requiring compact actuators
- Medical device component actuation
- Packaging machine ejector mechanisms
Installation note:
For optimal performance, maintain 0.5-1mm clearance between adjustable stoppers and cylinder body during stroke setting. Lubricate with ISO VG32 hydraulic oil if used in high-cycle (>5Hz) applications.
| Property | Property Value |
|---|---|
| sku | MFJ20X100-50 |
| Adjustable Stroke | <50mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
