Airtac MFJ Adjustable Mini Cylinder MFJ20X100-75
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X100-75 Technical Details
- Model Code: MFJ20X100-75
- Series: MFJ Compact Line
- Bore Size: 20mm (ISO 6432 compliant)
- Stroke: 100mm (±0.5mm tolerance)
- Adjustment Range: 75-125mm (via external stopper)
- Operating Pressure: 0.05-1.0 MPa
- Cushioning: Rubber bumper + adjustable air cushion
- Temperature Range: -10℃ to 70℃
- Port Size: M5x0.8 (dual Rc1/8 adapter included)
- Mounting Types: Basic front flange (MFJ-F), optional side lug (MFJ-L)
- Rod Thread: M6x1.0 (external)
- Body Material: Aluminum alloy (hard anodized)
- Seal Material: NBR (nitrile) with wear-resistant ring
- Weight: 540g ±2% (without accessories)
- Dimensions:
- Extended Length: 194mm
- Retracted Length: 94mm
- Body Width: 32mm
- Mounting Height: 40mm
Ultra-compact linear actuator featuring dual-position mechanical adjustability through its unique rotary stopper mechanism. The hardened piston rod with chromium plating ensures wear resistance in high-cycle applications (up to 15 million cycles at 0.5MPa). Integrated cushioning adjustment screw allows precise end-position deceleration control.
- PCB board clamping mechanisms in SMT production lines
- Precision part ejection systems in injection molding machines
- Lab automation sample positioning stages
- Medical device component alignment fixtures
- Semiconductor wafer handling robots
Installation protocol:
Apply MIL-PRF-81309 grease to guide bushings during assembly.
Maintain 0.5-1mm lateral clearance when using side-mounted variants.
Maximum side load capacity: 15N at full extension.
| Property | Property Value |
|---|---|
| sku | MFJ20X100-75 |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
