Airtac MFJ Adjustable Mini Cylinder MFJ20X100-75S
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X100-75S Specifications
- Model: MFJ20X100-75S
- Bore size: 20mm
- Stroke: 100mm (±0.5mm adjustment range)
- Operating pressure: 0.15–1.0 MPa
- Cushion type: Adjustable rubber cushion (both ends)
- Port size: M5×0.8 (standard), G1/8 optional
- Piston speed: 50–800 mm/s
- Ambient temperature: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy (hard anodized)
- Piston rod: SUS304 stainless steel
- Seals: NBR (nitrile rubber)
- Weight: 650g (1.43 lbs)
- Dimensions (L×W×H): 198mm × 32mm × 32mm (extended length)
- Mounting style: Standard side mounting with 75mm bracket span
- Lubrication: Pre-lubricated (use ISO VG32 or equivalent)
- Repeat accuracy: ±0.1mm
Ultra-compact cylinder featuring dual adjustable cushions and precision-ground rod for smooth linear motion. The anodized body resists corrosion in humid environments, while the magnetic piston enables position sensing integration. Designed for applications requiring space optimization without compromising force output (theoretical thrust: 62.8N at 0.5MPa).
- PCB handling robots in electronics manufacturing
- Micro-dosing valves in pharmaceutical packaging
- Optical lens positioning systems
- Semiconductor wafer clamping mechanisms
- 3D printer nozzle control systems
Installation tip:
For optimal performance, maintain 0.5–1mm alignment tolerance during bracket
mounting and install an air dryer when operating below 3℃ to prevent icing.
Minimum 5μm filtration recommended.
| Property | Property Value |
|---|---|
| sku | MFJ20X100-75S |
| Adjustable Stroke | 75mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Stroke | 100mm |
