Airtac MFJ Adjustable Mini Cylinder MFJ20X125-10
$43.70
Regular price
$51.20
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MFJ20X125-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JS standards;
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
Installation guidelines:
Apply Dow Corning Molykote 55 O-ring lubricant during assembly.
Maintain 0.5-1mm lateral clearance during alignment.
Maximum side load capacity: 15N at full extension.
Recommend replacing seals after 2 million cycles or 3 years (whichever comes first).
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ20X125-10 Adjustable Miniature Cylinder Specifications
- Model: MFJ20X125-10
- Type: Double-acting with adjustable cushioning
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 125mm (±0.5mm tolerance)
- Operating pressure: 0.15–0.8 MPa
- Cushion adjustment range: 3-25mm (threaded screw control)
- Piston speed: 50-800mm/s (optimal at 0.5 MPa)
- Mounting style: Standardized ISO 15552 front flange with 4x M5 threaded holes
- Port size: M5x0.8 pneumatic ports (dual acting)
- Rod end: M6x1.0 external thread
- Operating temperature: -20℃ to 80℃
- Seal material: Nitrile rubber (NBR) with wear-resistant guide rings
- Body material: Anodized aluminum alloy (6063-T5)
- Weight: 0.82kg (with standard accessories)
- Dimensions (L×W×H):
- Extended length: 257mm (stroke + cylinder length)
- Retracted length: 132mm
- Max width: 45mm (across mounting flange)
- Height: 34mm (body diameter)
- ISO certification: Compliant with ISO 6432:2015
A precision-engineered compact cylinder featuring progressive cushioning adjustment via hex-key accessible screws. The corrosion-resistant anodized finish and integrated mounting points enable seamless integration into tight spaces. Includes dual anti-rotation slots (3mm width) for stable rod alignment. Requires ISO 8573-1:2010 [4:4:3] class compressed air.
Ideal Applications:
- PCB handling robots in electronics manufacturing
- Precision clamping mechanisms in CNC tool changers
- Pharmaceutical blister packaging machines
- Semiconductor wafer processing equipment
- Automated optical inspection (AOI) systems
Installation guidelines:
Apply Dow Corning Molykote 55 O-ring lubricant during assembly.
Maintain 0.5-1mm lateral clearance during alignment.
Maximum side load capacity: 15N at full extension.
Recommend replacing seals after 2 million cycles or 3 years (whichever comes first).
| Property | Property Value |
|---|---|
| sku | MFJ20X125-10 |
| Adjustable Stroke | <10mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
