Airtac MFJ Adjustable Mini Cylinder MFJ20X125-100
$43.70
Regular price
$51.20
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
MFJ20X125-100
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Complies with JS standards;
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
Installation protocol:
Adjust cushion screws clockwise to increase damping (1/4 turn increments).
Maintain 0.3-1MPa lubrication pressure. Avoid side load exceeding 15N·m.
For vertical mounting, use rod-down orientation with ≤45° deviation.
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X125-100 Technical Details
- Model: MFJ20X125-100
- Type: Double-acting adjustable cushion cylinder
- Bore size: 20mm (ISO 6432 standard)
- Stroke: 125mm (±0.5mm tolerance)
- Operating pressure: 0.05-0.9 MPa
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (G1/8 adaptor optional)
- Cushion type: Adjustable rubber buffer (both ends)
- Mounting style: Basic type (accessory mounts available: MFJLM20)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Stainless steel (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 520g ±5g (without accessories)
- Dimensions:
- Total length: 195mm (stroke + cylinder body)
- Body diameter: 40mm (hexagonal cross-section)
- Rod end thread: M10x1.25
- Stroke adjustment range: ±2mm via cushion screw
- Max theoretical force: 28.3kgf@0.5MPa
- Air consumption: 3.92L/stroke (at 0.5MPa)
- ISO standard: Compliant with ISO 6432 (VDMA 24562)
Ultra-compact cylinder featuring dual adjustable cushioning for precise end-position control. The hexagonal body design enables tool-free rotation adjustment (360° mounting flexibility) and integrated mounting slots. Includes wear-resistant rod bearing for >2,000km service life under standard conditions. Requires ISO 8573-1:2010 Class 3 lubricated air (VG32 oil mist recommended).
Industrial Applications:
- PCB handling robots - precision component placement
- Medical device assembly - cleanroom compatible design
- Pharmaceutical packaging machines - smooth stroke control
- Semiconductor wafer carriers - low particle generation
- Textile machinery - high cycle rate (up to 120cpm)
Installation protocol:
Adjust cushion screws clockwise to increase damping (1/4 turn increments).
Maintain 0.3-1MPa lubrication pressure. Avoid side load exceeding 15N·m.
For vertical mounting, use rod-down orientation with ≤45° deviation.
| Property | Property Value |
|---|---|
| sku | MFJ20X125-100 |
| Adjustable Stroke | 100mm |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
