Airtac MFJ Adjustable Mini Cylinder MFJ20X125-20
2. Features an asymmetric bidirectional sealing structure for piston sealing, offering compact dimensions with integrated oil reservoir functionality;
3. Integrated fixed cushions on both end covers minimize impact during directional changes;
4. Multiple rear cover configurations simplify installation and enhance mounting flexibility;
5. Crimped and wrapped assembly ensures robust connection between stainless steel barrel and end covers;
6. Precision-engineered stainless steel barrel provides exceptional strength and corrosion resistance;
7. MF series achieves shorter overall length than ISO6432 standard cylinders while maintaining identical bore/stroke specifications;
8. Comprehensive range of cylinder variants and mounting accessories available for customized solutions.
Category: Adjustable Cylinders | Brand: AirTAC | Series: MFJ Adjustable cylinders
AirTAC MFJ Adjustable Miniature Cylinder MFJ20X125-20 Technical Details
- Model: MFJ20X125-20
- Bore size: 20mm
- Stroke: 125mm
- Adjustable cushioning: Dual-side adjustable (0-5mm stroke adjustment)
- Operating pressure: 0.15-0.8 MPa (21.7-116 psi)
- Temperature range: -20℃ to 80℃
- Port size: M5x0.8 (G1/8 optional)
- Mounting type: Standard foot mounting (MFJ series base)
- Piston material: High-strength aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal material: NBR (Nitrile rubber)
- Weight: 0.63kg ±2%
- Dimensions (L×W×H): 225mm × 20mm × 20mm (full extension length)
- Max theoretical thrust: 24.5N at 0.6MPa
- Cushion screw rotation range: 180°±5°
- Lubrication: Pre-lubricated (Grease-free operation)
- ISO standard: 6432 compliant
Ultra-compact cylinder featuring precision-machined cushion screws for smooth end-stroke deceleration control. The hardened piston rod and triple-lip seal design ensure 3,000km+ service life under standard conditions. Special anti-rotation mechanism maintains tooling alignment during high-speed reciprocation (max 2.0m/s). Includes built-in magnetic sensor slot for position feedback integration.
- PCB handling robots - component insertion/removal
- Pharmaceutical blister packaging machines
- Micro-precision clamping in watch manufacturing
- Cleanroom semiconductor wafer positioning
- High-cycle textile machinery thread control
Installation protocol:
Align cylinder axis within 0.2mm perpendicular tolerance. For vertical mounting,
reduce operating pressure by 15% to compensate for gravity load.
Perform cushion adjustment at 80% of maximum operating speed.
| Property | Property Value |
|---|---|
| sku | MFJ20X125-20 |
| Adjustable Stroke | <20mm> |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <20mm> |
| Stroke | 125mm |
